Skyjacker Suspension F8852KH-X 8.5 Inch Lift Kit with ADX 2.0 Shocks

The Skyjacker F8852KH-X is a comprehensive 8.5-inch suspension lift system engineered for 2008 Ford F-350 4WD diesel trucks, featuring coil springs, track bar bracket, steering stabilizer, sway bar links, brake lines, radius arm brackets, 4-link arms, rear leaf springs, and U-bolts. This system includes Skyjacker's innovative 4-Link Conversion that replaces OEM radius arms with integrated radius arm drop brackets plus upper and lower adjustable control arms formed from 2-inch OD x 0.250 wall DOM tubing.

ADX 2.0 Adventure Series Shocks:

The kit includes ADX 2.0 Adventure Series Remote Reservoir Aluminum Monotube Shocks that deliver race-inspired full-displaced custom valve tuned system, providing consistent dampening, high-end performance, cooler running, more control, and improved driving comfort. These shocks feature impact extruded CNC machined T6061-T6 aluminum monotube construction with a large 53.5mm body OD and 46mm ID bore size, utilizing high pressure nitrogen gas and IFP technology. The separate remote reservoir allows more room in the shock cylinder to increase oil capacity and use a longer piston rod for more piston stroke and articulation travel.

Key Features:

• Adjustable Flex Links allow proper caster settings to improve handling
• T6061-T6 aluminum construction dissipates heat, runs cooler, and weighs less than steel-bodied shocks
• Teflon banded piston delivers smooth reaction and superior ride performance with added stability on various terrains
• Custom valve tuned, vehicle-specific dampening for optimal performance
• Engineered for higher speed applications while still performing at crawl speeds

Important Notes:

• Does not fit models with gas engine
• Part # FA450 Pitman Arm is required
• If equipped with rear sway bar, order extended end links Part # SBE406
• Professional installation by a certified mechanic is strongly recommended

Skyjacker Suspension Lift Kits provide a smooth, comfortable ride while responding to on or off-road conditions, helping you achieve the right height, clearance, and attitude while maintaining factory ride quality and improving handling.
