Skyjacker F8852K-X 8.5 Inch Suspension Lift Kit with ADX 2.0 Remote Reservoir Shocks

The Skyjacker F8852K-X delivers an impressive 8.5-inch suspension lift system engineered specifically for 2008-2010 Ford F250 4WD diesel models. This comprehensive kit transforms your Super Duty's capability through an advanced 4-Link conversion system that replaces factory radius arms with precision-engineered adjustable control arms.

4-Link Conversion System:

• Upper and lower adjustable Flex Links formed from 2-inch OD x 0.250 wall DOM tubing
• Forked clevis end at lower axle mount with 1-1/4 inch forged rod end at upper bracket
• Integrated radius arm drop brackets maintain proper caster settings for improved handling
• Steel-encased rubber bushings for durability and controlled articulation

Front Suspension Components:

• 2-Stage Variable Rate coil springs specifically engineered for F250 4WD diesel weight and performance
• Heavy-duty track bar relocation bracket captures front crossmember on both sides
• Front sway bar brackets and brake line brackets with braided stainless steel lines
• Drop brackets for bump stop repositioning

Rear Suspension Components:

• Softride Technology leaf springs with tapered leafs for even load distribution
• Enhanced flex at leaf ends for improved articulation
• Heavy-duty U-bolts and mounting hardware included

ADX 2.0 Remote Reservoir Monotube Shocks:

• Race-inspired full-displaced valving system with custom valve tuning
• Impact-extruded CNC machined T6061-T6 aluminum monotube body
• Nitrogen charged with Internal Floating Piston Technology for quickest shock reaction time
• Remote reservoir design runs cooler and provides consistent damping performance
• Optimized for both high-speed off-road and daily driving comfort

This complete lift system includes all necessary mounting hardware and detailed installation instructions. The kit provides the ground clearance needed for larger tires while maintaining factory ride quality and improving overall handling characteristics both on and off-road.

Important Notes: Does not fit models with gas engines. Pitman arm (Part # FA450) is required and sold separately. If equipped with rear sway bar, extended end links (Part # SBE406) may be required.
