Skyjacker F8601KSH-X 6 in. Suspension Lift System with ADX 2.0 Remote Reservoir Monotube Shocks

The Skyjacker F8601KSH-X is a complete 6-inch suspension lift system engineered specifically for the 2008 Ford F-350 Super Duty 4WD with a gas engine. This comprehensive kit delivers a genuine suspension lift — not a spacer — providing increased ride height, greater ground clearance, and the ability to run larger tires while maintaining structural integrity and factory geometry angles.

At the heart of this system are Skyjacker's ADX 2.0 Adventure Series Remote Reservoir Aluminum Monotube Shocks, purpose-built to enhance both front and rear damping performance. The shocks feature an off-road race-inspired full-displaced valving system and are engineered to perform at both high speeds and slow crawl speeds, making them equally capable on the trail or the highway.

ADX 2.0 Shock Technology:

• External remote reservoir separates nitrogen gas from oil using an Internal Floating Piston (IFP)
• IFP technology prevents gas and oil from mixing or foaming (cavitation) for consistent damping
• Nitrogen-charged IFP design delivers the quickest shock reaction time for improved control and stability
• Specific valving and stroke tuned for this exact application and ride height
• Aluminum monotube construction for superior heat dissipation under demanding off-road use

Lift System Features:

• Full 6-inch suspension lift with front and rear componentry
• Gas engine-specific front coil springs engineered with Skyjacker's Softride® technology for maximum wheel travel and ride quality
• Radius arm drop brackets to correct caster specifications and maintain proper alignment
• Track bar relocation bracket to keep the front axle centered
• Drop pitman arm to correct steering geometry
• Sway bar lowering brackets for maximum sway control
• Bump stop drop spacers to reposition front bump stops
• Front brake line extension brackets to correctly reposition brake lines
• All necessary mounting hardware and detailed installation instructions included

Important Notes: This kit is designed for the gas engine variant of the 2008 Ford F-350 Super Duty 4WD. Professional installation is recommended. Additional components such as an extended front driveshaft may be required depending on vehicle configuration.
