Wilwood 340-16604 Triple Pedal Assembly Adjustable Floor Mount with Tru-Bar

Manufacturer

Part Number

340-16604
Black Friday Price

$732.55

In Stock (10)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wilwood 340-16604 is a complete floor-mount triple pedal assembly designed specifically for rear-engine vehicles, featuring an adjustable-ratio Tru-Bar brake pedal, clutch pedal, and throttle pedal. This high-performance pedal system provides precise control and customization for racing and high-performance street applications.

Adjustable Brake Pedal Ratio: The brake pedal head adjusts vertically to provide three different pedal ratios—4.75:1, 5.25:1, or 5.75:1—allowing drivers to fine-tune pedal feel and effort to match their preference and braking system requirements.

Tru-Bar Balance Bar System: Features Wilwood's friction-free, trunnion-based adjustable Tru-Bar balance bar that enables precise front-to-rear brake bias tuning. The Tru-Bar incorporates positive detent stops every full turn to maintain adjustment position and includes a jam nut for locking settings, or can be used with an optional remote adjustment knob for on-track changes. The system utilizes fixed trunnion bearings in the pedal arms with spherical rod-end bearing pushrod attachments, reducing compliance and friction for superior brake modulation and feel.

Key Features:

  • Lightweight aluminum frame construction with high-strength reinforced I-beam style forged pedal arms
  • Non-skid waffled pedal pads with lateral adjustment capability
  • Clutch and brake pedals adjust laterally from 3.75 to 5.75 inches on center for driver comfort
  • Throttle pedal includes pull rod for rear-engine applications
  • Accommodates one clutch and two brake master cylinders
  • Accepts three Wilwood 2.25-inch vertical mount flange single outlet master cylinders (sold separately)
  • Compatible with Wilwood master cylinders available in various bore sizes
  • Uses same chassis and master cylinder mounting as Wilwood balance bar style pedals

This premium pedal assembly delivers professional-grade performance with exceptional adjustability, making it ideal for serious racers and performance enthusiasts who demand precise, consistent pedal feel and the ability to fine-tune their brake bias on the fly.
