June Sale: $12.33
In Stock
May ship from manufacturer
Free Shipping
Part number: CFL-3
Product Details
QA1 Precision Products CFL-3 Rod End - 3/16in x 10-3LH Steel- Female
Products specifications
A (+/-0.015) 1.062
Approx Bearing Weight 0.04
B (+0.0025/-0.0005) 0.19
Ball Dia Ref 0.437
C (+0.062/-0.031) 0.5
D Ref 0.625
E (+/-0.010) 0.406
F (+/-0.010) 0.312
Grease Fitting No
Heat-Treated Yes
Jam Nut Included No
Misalign Angle 20
Quantity Sold individually.
Rod End Attachment Female threads
Rod End Ball Width 0.312 in.
Rod End Centerline Length 1.062 in.
Rod End Construction 2-piece
Rod End Finish Zinc plated
Rod End Head Bore Size 0.190 in.
Rod End Head Diameter 0.625 in.
Rod End Head Width 0.312 in.
Rod End Material Carbon steel
Rod End Misalign Angle (degrees) 20 degrees
Rod End Static Load Capacity 2,079 lbs.
Rod End Style Metal to metal
Rod End Thread Size 10-32 LH NF
Thread Length 0.500 in.
Thread Type Left Hand
Thread UNF-2B 10-32
UTL Radical Static 2079
W (+/-0.005) 0.312
QA1 Precision Products Rod End - 3/16in x 10-3LH Steel- Female
