ICON Vehicle Dynamics K53211T 2-3.25" Lift Stage 1 3.0 Suspension System for 22-23 Toyota Tundra

The ICON Vehicle Dynamics Stage 1 3.0 Suspension System delivers a complete front and rear suspension upgrade for the 2022-2023 Toyota Tundra, combining premium components engineered for superior on-road comfort and extreme off-road capability. This comprehensive system provides adjustable lift heights from 2 to 3.25 inches and supports tire sizes up to 35 inches.

Front Suspension Components:

• 3.0 Series Remote Reservoir Coilovers - Vehicle-specific design with CDC (Compression Damping Control) valves offering 10 levels of adjustable compression damping. Features 50% more piston surface area in the ride zone and 100% more in the Bump Zone compared to 2.5 Series shocks.
• Multi-Stage Hydraulic Bump Zone - Exponentially increases bottom-out resistance through the last 40% of shock travel, providing up to 40% more wheel travel than stock for improved control over harsh terrain.
• Tubular Upper Control Arms - High-strength tubular construction with corrected geometry, built-in additional caster, and improved component clearance. Features the patented Delta Joint Pro (U.S. Pat. 10,731,700) with 90 degrees of total articulation, eliminating bind through full suspension travel.
• Sway Bar Drop Brackets - Minimizes sway bar link bind throughout suspension travel, allowing unrestricted wheel movement without overstressing OE components.

Rear Suspension Components:

• 2.5 Aluminum Series Remote Reservoir Shocks - CDC valve-equipped shocks with 10 compression damping settings and internal Bump Zone providing 20% additional damping force. Remote reservoirs maintain consistent performance and cooler operating temperatures during heavy use.
• Tubular Steel Adjustable Upper and Lower Links - Constructed from 1-3/4 inch x .313 wall DOM tubing with multi-stage black powder coat finish. PTFE-lined FK rod ends provide increased articulation and reduced deflection, while multi-durometer bushings ensure quiet operation without periodic maintenance.

Key Benefits:

• Adjustable ride height from 2 to 3.25 inches for proper stance and fitment of aggressive wheel and tire combinations
• Externally adjustable compression damping allows fine-tuning for different driving conditions and loads
• Improved alignment specifications and front-end geometry for better drivability and tire wear
• Maximum wheel travel and articulation for confident off-road performance
• Balanced front-to-rear damping characteristics for superior vehicle control
• Serviceable and rebuildable components for long-term durability

This Stage 1 system represents a significant upgrade over the Stage 10 2.5 system, offering enhanced performance through larger shock bodies, increased damping control, and improved suspension geometry. The combination of adjustable coilovers, remote reservoir shocks, and precision-engineered control arms delivers exceptional performance whether navigating city streets or conquering challenging off-road terrain.
