The Skyjacker G351RKXLTD is a complete 3.5-inch suspension lift system engineered specifically for the Jeep Gladiator, featuring advanced ADX 2.0 Remote Reservoir shocks and comprehensive suspension components for superior off-road performance and daily driving comfort.
Progressive Dual-Rate Coil Springs:
Skyjacker's engineered 2-stage dual rate long travel coils deliver exceptional versatility. The first flex rate stage provides comfortable on-road handling while allowing increased articulation during off-road use. This flex rate expands during full droop to keep coil springs properly seated and tires in contact with terrain. The second ride rate stage engages after compression past the flex rate for controlled damping. Rear coils are side-specific to coordinate with the Gladiator's unique suspension geometry.
ADX 2.0 Adventure Series Remote Reservoir Shocks:
These aluminum monotube shocks feature race-inspired full-displaced valving technology optimized for high-speed desert running while maintaining excellent low-speed crawling performance. The external remote reservoir separates nitrogen gas from oil using an Internal Floating Piston (IFP) to prevent cavitation and foaming, ensuring consistent damping across all conditions.
Suspension Geometry Correction Components:
- Extended front lower control link arms correct caster angle with inward offset bends for improved tire clearance and maximum turning radius
- Longer rear upper control link arms properly correct rear driveshaft pinion angle
- Both arm sets constructed from 2-inch OD x 0.250-wall DOM tubing with pressed-in heavy-duty OEM-style vulcanized rubber bushings
- Adjustable front track bar with HD rubber bushing and 3/4-inch heavy-duty rod end with jam nut and alignment bushings
Complete Hardware Package:
- Front and rear bump stop spacers bolt to axle bump pads to safely control suspension travel
- Extended-length sway bar end links allow full articulation at droop
- Front end links feature pressed-in HD OEM-style rubber bushings
- Rear end links include press-in polyurethane bushings
This comprehensive system provides the perfect balance of lifted stance, improved off-road capability, and maintained on-road handling characteristics for Jeep Gladiator owners seeking serious performance upgrades.
