Skyjacker Suspension G351KXLTD Lift Kit with ADX Remote Reservoir Shocks - 3.5 Inch 2.0

The Skyjacker G351KXLTD is a complete 3.5-inch suspension lift system engineered specifically for the Jeep Gladiator, featuring premium ADX 2.0 Adventure Series remote reservoir shocks and comprehensive suspension components for superior off-road performance.

Progressive Dual-Rate Coil Springs:

This system utilizes Skyjacker's advanced 2-stage dual rate long travel coil springs designed specifically for the Gladiator's unique suspension geometry. The first Flex Rate stage provides a comfortable on-road ride while allowing maximum articulation during off-road use. As the suspension drops to full droop, the flex rate expands to keep coil springs properly seated and maintain tire contact with terrain. The second Ride Rate stage engages only after compression past the flex rate, providing progressive spring response. Rear coils are side-specific, engineered to coordinate with the Gladiator's distinctive handling characteristics.

ADX 2.0 Remote Reservoir Shocks:

The included ADX 2.0 Adventure Series aluminum monotube shocks deliver race-inspired performance with full-displaced valving technology. The external remote reservoir design separates nitrogen gas from oil using an Internal Floating Piston (IFP), preventing gas and oil mixing or cavitation. This configuration ensures consistent performance from high-speed desert running to technical rock crawling.

Complete Control Arm Package:

• Longer front lower control link arms correct caster angle with inward offset bend for improved tire clearance and maximum turning radius
• Longer rear upper control link arms correct rear driveshaft pinion angle
• All arms formed from 2-inch OD x 0.250 wall DOM tubing with pressed-in heavy-duty OEM-style vulcanized rubber bushings at each end

Additional Components Included:

• Adjustable front track bar with pressed-in heavy-duty OEM-style rubber bushing, 3/4-inch heavy-duty rod end, jam nut, and alignment bushings
• Front and rear bump stop spacers that bolt onto axle bump pads to safely control suspension travel
• Extended-length sway bar end links allow full articulation at full droop
• Front end links feature pressed-in heavy-duty OEM-style rubber bushings
• Rear end links include press-in polyurethane bushings

This comprehensive lift system provides everything needed to safely lift your Jeep Gladiator 3.5 inches while maintaining proper suspension geometry, driveline angles, and ride quality for both on-road comfort and serious off-road capability.
