EBC BC4102R-L Apollo-4R Race Brake Caliper 4-Piston Front Left

The EBC BC4102R-L Apollo-4R is a lightweight yet strong aluminum brake caliper featuring a 2-piece bolted design with high-tensile 12.9 Grade steel bolts for reinforcement of the caliper bridge section, resulting in improved caliper stiffness and a firmer and more responsive pedal feel, especially after periods of harder braking.

Key Features:

• 4-piston design for balanced, high-performance braking
• Front left (driver side) trailing axle position configuration
• Compatible with 300mm or 355mm diameter brake discs
• Designed for 28mm disc thickness on 2-piece rotors
• Machined from heat-treated low-pressure castings for superior consistency and performance advantage over conventional gravity cast calipers
• Hard anodized finish recommended for track and/or competition use only (no dust boots)
• FEA-optimized aluminum caliper body reinforced with grade 12.9 bridge bolts for class-leading stiffness
• Stainless steel bleed nipples and wear plates for enhanced durability
• Uses common pad shape with multiple race formulations available - not limited to EBC pads
• Manufactured 100% in the UK - cast, machined, assembled, and pressure tested

The Apollo-4R series offers a noticeable performance advantage over conventional gravity cast calipers, exhibiting higher overall strength and caliper body stiffness comparable to forged calipers. The hard anodized finish provides exceptional durability for demanding racing and track day applications where maximum performance is required.

Note: This is a race-spec caliper without dust boots, designed specifically for motorsport applications. For street use, consider the standard Apollo series with protective dust boots.
