ICON Vehicle Dynamics K40017T Stage 7 Suspension System 2-3" Lift Bronco Sasquatch Tubular UCA

The ICON Vehicle Dynamics Stage 7 Suspension System for 2021-2023 Ford Bronco Sasquatch represents the ultimate suspension upgrade, delivering exceptional performance both on-road and off-road. This comprehensive system features custom-valved remote reservoir coilover shocks with adjustable CDC Valves (Compression Damping Control Valves), allowing precise tuning for any terrain from rock crawling to high-speed desert running.

Suspension Performance:

• Up to 11.5" front and 14" rear wheel travel with 35" tire fitment
• Adjustable 2-3" front lift height and 1.25-2.25" rear lift height over stock Sasquatch 4-door Broncos
• Vehicle-specific tuned remote reservoir coilover shocks front and rear for superior damping and control
• Remote reservoirs increase shock oil volume and heat dissipation to prevent fade during hard use
• Triple-rate rear coil springs with shaft-up shock orientation maximize travel and ride quality

Complete System Includes:

• Tubular upper control arms with patented Delta Joint PRO technology featuring up to 90° articulation
• Complete tubular rear link kit with upper and lower links
• Adjustable rear track bar with dual-durometer greaseless bushings and FK rod ends
• PTFE-lined spherical bearings and application-specific mounting hardware
• Greaseless bushings and massive FK rod ends designed for clearance during maximum articulation

Delta Joint PRO Technology:

• Fully rebuildable and serviceable design with replaceable components
• 56% more bearing surface than standard Delta Joints for enhanced durability
• Chromoly ball and shaft with Rockwell C 55 hardened bearing surface
• Sealed design protects from elements, road salt, and debris
• Improved lubrication system with efficient grease distribution channels

This Stage 7 system corrects suspension geometry for proper caster alignment on lifted applications while providing bind-free suspension movement through the complete range of travel. Designed for use with 35x12.50 tires as optimized fitment, though compatible with 37" and larger tires when using optional up-travel limiters (sold separately).

Note: This system is specifically engineered for 2021-2023 Ford Bronco 4-door models equipped with the Sasquatch Package.
