JE Pistons Pro Seal File-Fit Piston Ring Sets

(Honda CRF450R 2002-09, 2011, CRF150R 2007-09, CRF250R 2004-09, CRF250X 2004-09, CRF450X 2005-09, XR400R 1996-2004; Yamaha YFZ450 2004-09 + 8 more models)

Manufacturer

Part Number

492 part numbers · from $13.99
Sale Price

from $13.99

In Stock (10+)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Select Your Vehicle:

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

JE Pistons Pro Seal File-Fit Piston Ring Sets deliver race-proven ring technology engineered to maximize combustion pressure sealing and horsepower output across a wide range of performance engine applications. Trusted by championship-winning teams in NASCAR, NHRA Pro Stock, ALMS, and AMA competition, the Pro Seal line brings elite-level ring technology to performance engine builders at every level.

The file-fit design places end-gap control directly in the engine builder's hands, allowing precise tuning for any bore size, application, and operating environment. This critical advantage supports naturally aspirated, turbocharged, and supercharged induction systems equally, making Pro Seal ring sets one of the most versatile options available to serious builders.

Key Features:

  • File-Fit End-Gap Configuration — puts full control over end-gap specification in the builder's hands, enabling precise tailoring to bore size and operating conditions
  • Premium Top Ring Construction — barrel-faced ductile iron top rings featuring a plasma-moly inlay that combines molybdenum, nickel, chrome, and trace elements for superior temperature resistance, reduced wear, and improved sealing
  • Engineered Second Ring Design — taper-faced, reverse-torsional second rings with phosphate coating for reliable combustion gas control
  • Low-Tension Oil Ring Options — available in low- and standard-tension configurations to reduce parasitic friction while maintaining effective oil control
  • Advanced Coatings and Surface Treatments — options include back cutting, dyke cutting, lapping, grinding, and PVD coating for specialized competition applications
  • Broad Induction Compatibility — engineered for naturally aspirated, turbocharged, and supercharged engine configurations
  • Wide Material and Thickness Selection — multiple ring materials and thicknesses available to suit diverse engine types, displacements, and build goals
  • Flexible Ordering Options — available per cylinder or as complete sets to match exact build requirements

JE Pistons designs, forges, and machines its products entirely in-house, ensuring strict quality control at every stage of production. The same ring technology and services relied upon by elite professional racing programs are available across the entire Pro Seal product line, delivering measurable gains in ring seal, friction reduction, and long-term durability that serious engine builders demand.

Products specifications

Fits

Honda CRF450R 2002-09, 2011, CRF150R 2007-09, CRF250R 2004-09, CRF250X 2004-09, CRF450X 2005-09, XR400R 1996-2004; Yamaha YFZ450 2004-09, YZ250F 2006, 2009, YZ450F 2006, 2009, 2011-13; Kawasaki KFX450R 2008-09, KFX700 2005-09 + 4 more models

Select yours to see vehicle-specific options.

Select & Customize

492 of 494 items

Description
Specifications
2nd Ring (Heigh/Width/Type)0.8mm / 0.109 / DPA
Bore69.00mm(2.717in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)1.5mm / 0.950 / CUF
Oil Ring Thickness0.059
Out of Stock MessageCall for Availability
Second Compression Ring Thickness0.0315
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0315
Top Ring (Heigh/Width/Type)0.8mm / 0.109 / CUS
Top Ring Facing MaterialChrome
Top Ring MaterialCarbon Steel
$32.08
PART NUMBER: XA6900
In Stock (6)
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.138 / DPE
Bore82.55 mm(3.250 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.126 / CNS
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$41.99
PART NUMBER: JG1001-3250
In Stock (5)
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.146 / DPE
Bore87.00 mm(3.425 in)
Bore (in)3.425 in.
Bore (mm)86.995mm
Category HierarchyAccessories>Rings>Ring Sets
File FitNo
File FitYes
GaplessNo
IndustryAutomotive
NotesSingle cylinder only. Napier® design second ring.
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring IncludedYes
Oil Ring MaterialNitride coated carbon steel
Oil Ring TensionLow
Oil Ring Thickness2.8mm
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
QuantitySold as a set.
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate coated
Second Ring Facing MaterialPhosphate
Second Ring IncludedYes
Second Ring MaterialDuctile iron
Second Ring Thickness1.2mm
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.134 / CNS
Top Ring Facing MaterialGas nitrided
Top Ring Facing MaterialNitride
Top Ring IncludedYes
Top Ring MaterialSteel
Top Ring MaterialCarbon Steel
Top Ring Thickness1.0mm
$41.99
PART NUMBER: JG1001-3425
4 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.142 / DPE
Bore84.00 mm(3.307 in)
Bore (in)3.307 in.
Bore (mm)83.998mm
Category HierarchyAccessories>Rings>Ring Sets
File FitNo
File FitYes
GaplessNo
IndustryAutomotive
NotesSingle piston set. Barrel face backcut neutral top ring, Napier backcut neutral second ring with flex vent-style oil ring.
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring IncludedYes
Oil Ring MaterialNitride coated carbon steel
Oil Ring TensionLow
Oil Ring Thickness2.8mm
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
QuantitySold as a set.
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate coated
Second Ring Facing MaterialPhosphate
Second Ring IncludedYes
Second Ring MaterialDuctile iron
Second Ring Thickness1.2mm
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.126 / CNS
Top Ring Facing MaterialGas nitrided
Top Ring Facing MaterialNitride
Top Ring IncludedYes
Top Ring MaterialSteel
Top Ring MaterialCarbon Steel
Top Ring Thickness1.0mm
$41.99
PART NUMBER: JG1001-3307
4 left at this price
Usually delivered within 2 days
Description
Specifications
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring Thickness0.098
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$45.99
PART NUMBER: JG4901-3917
4 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.171 / IPA
Bore97.50 mm(3.839 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)4.0mm / 0.138 / CUS
Oil Ring Thickness0.158
Out of Stock MessageCall for Availability
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.147 / CUS
Top Ring Facing MaterialChrome
Top Ring MaterialCarbon Steel
$30.99
PART NUMBER: XH9750
4 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.146 / DPE
Bore86.50 mm(3.405 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.134 / CNS
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$41.99
PART NUMBER: JG1001-3405
3 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.138 / DPE
Bore83.00 mm(3.268 in)
Bore (in)3.268 in.
Bore (mm)83.000mm
Bore Diameter3.268
Category HierarchyAccessories>Rings>Ring Sets
File FitNo
File FitYes
GaplessNo
IndustryAutomotive
NotesSingle piston set. Barrel face back cut neutral top ring, Napier back cut neutral second ring with flex vent style oil ring.
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring IncludedYes
Oil Ring MaterialNitride coated carbon steel
Oil Ring TensionLow
Oil Ring Thickness2.8mm
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
QuantitySold as a set.
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate coated
Second Ring Facing MaterialPhosphate
Second Ring IncludedYes
Second Ring MaterialDuctile iron
Second Ring Thickness1.2mm
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.126 / CNS
Top Ring Facing MaterialGas nitrided
Top Ring Facing MaterialNitride
Top Ring IncludedYes
Top Ring MaterialSteel
Top Ring MaterialCarbon Steel
Top Ring Thickness1.0mm
$41.99
PART NUMBER: JG1001-3268
3 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.150 / DPE
Bore90.00 mm(3.543 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.134 / CNS
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$41.99
PART NUMBER: JG1001-3543
3 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.0mm / 0.124 / DPA
Bore80.00 mm(3.150 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.0mm / 0.132 / CUS
Oil Ring Thickness0.079
Out of Stock MessageCall for Availability
Second Compression Ring Thickness0.0394
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.124 / CUS
Top Ring Facing MaterialChrome
Top Ring MaterialCarbon Steel
$32.99
PART NUMBER: XG8000
3 left at this price
Usually delivered within 2 days
Description
Specifications
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$41.99
PART NUMBER: JG1001-3652
3 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.138 / DPE
Bore81.50 mm(3.209 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.126 / CNS
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$45.99
PART NUMBER: JG1001-3209
2 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.142 / DPE
Bore86.00 mm(3.386 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.126 / CNS
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$41.99
PART NUMBER: JG1001-3386
2 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)/ /
Bore96.00 mm(3.780 in)
Category HierarchyAccessories>Rings>Ring Sets
CommentsPro Series
Distinct NameRing Set - 96.00mm
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.0mm / 0.106 / CUF
Oil Ring Thickness0.079
Out of Stock MessageCall for Availability
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0374
Top Ring (Heigh/Width/Type)0.95mm / 0.127 / CNN
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$38.49
PART NUMBER: ZV9600
2 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.0mm / 0.132 / DPA
Bore83.00 mm(3.268 in)
Bore Diameter3.268
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.0mm / 0.132 / CUS
Oil Ring Thickness0.079
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0394
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.124 / CUS
Top Ring Facing MaterialChrome
Top Ring MaterialCarbon Steel
$33.99
PART NUMBER: XG8300
1 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.158 / DPE
Bore94.00 mm(3.701 in)
Bore (in)3.701 in.
Bore (mm)94.000mm
Bore Diameter3.701
Category HierarchyAccessories>Rings>Ring Sets
Distinct NameRing Set - 94.00mm
File FitNo
File FitYes
GaplessNo
IndustryAutomotive
NotesSingle piston set. Barrel face back cut neutral top ring, Napier back cut neutral second ring with full seal flex vent style oil ring.
Oil Ring (Heigh/Width/Type)2.0mm / 0.118 / CUF
Oil Ring IncludedYes
Oil Ring MaterialChrome plated carbon steel
Oil Ring TensionLow
Oil Ring Thickness2.0mm
Oil Ring Thickness0.079
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
QuantitySold as a set.
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate coated
Second Ring Facing MaterialPhosphate
Second Ring IncludedYes
Second Ring MaterialDuctile iron
Second Ring Thickness1.2mm
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.142 / CNS
Top Ring Facing MaterialGas nitrided
Top Ring Facing MaterialNitride
Top Ring IncludedYes
Top Ring MaterialSteel
Top Ring MaterialCarbon Steel
Top Ring Thickness1.0mm
$45.99
PART NUMBER: JG1101-3701
1 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1.2mm / 0.142 / DPE
Bore83.50 mm(3.287 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.8mm / 0.128 / CNF
Oil Ring Thickness0.110
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0472
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.126 / CNS
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$41.99
PART NUMBER: JG1001-3287
1 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ringnone
Bore77.00mm(3.031in)
Category HierarchyAccessories>Rings>Ring Sets
Distinct NameRing Set - 77.00mm
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)1.5mm / 0.094 / CUF
Oil Ring Thickness0.059
Out of Stock MessageCall for Availability
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0354
Top Ring (Heigh/Width/Type)0.9mm / 0.108 / CUR
Top Ring Facing MaterialChrome
Top Ring MaterialCarbon Steel
$30.99
PART NUMBER: JC3301-3031
1 left at this price
Usually delivered within 2 days
Description
Specifications
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring Thickness0.059
Out of Stock MessageCall for Availability
Second Compression Ring Thickness0.0315
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0315
Top Ring Facing MaterialChrome
Top Ring MaterialCarbon Steel
$32.08
PART NUMBER: XA6200
1 left at this price
Usually delivered within 2 days
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.187 / IPT
Bore101.60 mm(4.000 in)
Bore Diameter4.000
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.152 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.152 / SGR
Top Ring Facing MaterialTitanium Nitride
Top Ring MaterialStainless steel
$81.99
PART NUMBER: J95001-4000-3
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.167 / IPL
Bore98.00 mm(3.858 in)
Bore Diameter3.858
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.156 / IPD
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialIron
Third Ring MaterialIron
Top Compression Ring Thickness0.0591
Top Ring (Heigh/Width/Type)1.5mm / 0.167 / IPL
Top Ring Facing MaterialPhosphate
Top Ring MaterialIron
$86.13
PART NUMBER: J612U1-3858
Ships from manufacturer
Description
Specifications
2nd Ring1.5mm
Bore102.62mm(4.040in)
Bore (in)4.040 in.
Bore (mm)102.616mm
Bore Diameter4.040
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
GaplessNo
IndustryAutomotive
NotesSingle piston set. Barrel face back cut torsional top ring, Napier back cut neutral second ring with full seal flex vent style oil ring.
Oil Ring3.0mm
Oil Ring IncludedYes
Oil Ring MaterialChrome plated carbon steel
Oil Ring TensionLow
Oil Ring Thickness3.0mm
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
QuantitySold as a set.
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate coated
Second Ring Facing MaterialPhosphate
Second Ring IncludedYes
Second Ring MaterialIron
Second Ring Thickness1.5mm
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring1.2mm
Top Ring Facing MaterialPlasma-moly
Top Ring Facing MaterialPlasma Moly
Top Ring IncludedYes
Top Ring MaterialSteel
Top Ring MaterialCarbon Steel
Top Ring Thickness1.2mm
$51.99
PART NUMBER: J75001-4040-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.212 / IPT
Bore117.09 mm(4.610 in)
Bore Diameter4.610
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3 / 16 / 0.190 / CUS
Oil Ring Thickness0.188
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.064
Top Ring (Heigh/Width/Type)1 / 16 / 0.212 / DMB
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialDuctile iron
$62.99
PART NUMBER: J100H1-4610-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.75mm / 0.165 / IPE
Bore102.01 mm(4.016 in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.150 / IPD
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0689
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialIron
Third Ring MaterialIron
Top Compression Ring Thickness0.0591
Top Ring (Heigh/Width/Type)1.5mm / 0.165 / IPA
Top Ring Facing MaterialPhosphate
Top Ring MaterialIron
$76.99
PART NUMBER: J660U1-4016
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore103.12mm(4.060in)
Bore Diameter4.060
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.152 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$48.99
PART NUMBER: J75001-4060-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore104.78mm(4.125in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.150 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J75001-4125-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore104.90mm(4.130in)
Bore Diameter4.130
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.152 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J75001-4130-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore105.03mm(4.135in)
Bore Diameter4.135
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.152 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J75001-4135-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore105.28mm(4.145in)
Bore Diameter4.145
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.152 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J75001-4145-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore105.79mm(4.165in)
Bore Diameter4.165
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.152 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J75001-4165-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore102.62mm(4.040in)
Bore Diameter4.040
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.146 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$48.99
PART NUMBER: J750F1-4040-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore103.12mm(4.060in)
Bore Diameter4.060
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.146 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$48.99
PART NUMBER: J750F1-4060-5
Ships from manufacturer
Description
Specifications
2nd Ring1.5mm
Bore104.78mm(4.125in)
Bore Diameter4.125
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring3.0mm
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring1.2mm
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$48.99
PART NUMBER: J750F1-4125-5
Ships from manufacturer
Description
Specifications
2nd Ring1.5mm
Bore105.03mm(4.135in)
Bore Diameter4.135
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring3.0mm
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring1.2mm
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J750F1-4135-5
Ships from manufacturer
Description
Specifications
2nd Ring1.5mm
Bore105.28mm(4.145in)
Bore Diameter4.145
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring3.0mm
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring1.2mm
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J750F1-4145-5
Ships from manufacturer
Description
Specifications
2nd Ring1.5mm
Bore105.79mm(4.165in)
Bore Diameter4.165
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring3.0mm
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring1.2mm
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$48.99
PART NUMBER: J750F1-4165-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.165 / IPT
Bore96.00 mm(3.780 in)
Category HierarchyAccessories>Rings>Ring Sets
Distinct NameRing Set - 96.00mm
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.0mm / 0.106 / CUF
Oil Ring Thickness0.079
Out of Stock MessageCall for Availability
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0374
Top Ring (Heigh/Width/Type)0.95mm / 0.127 / CNN
Top Ring Facing MaterialNitride
Top Ring MaterialCarbon Steel
$73.95
PART NUMBER: JG5001-3780
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.0mm / 0.124 / DPA
Bore76.00mm(2.992in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)2.0mm / 0.132 / CUS
Oil Ring Thickness0.079
Out of Stock MessageCall for Availability
Second Compression Ring Thickness0.0394
Second Ring Facing MaterialPhosphate
Second Ring MaterialDuctile iron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0394
Top Ring (Heigh/Width/Type)1.0mm / 0.116 / CUS
Top Ring Facing MaterialChrome
Top Ring MaterialCarbon Steel
$30.99
PART NUMBER: XG7600
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.208 / IPT
Bore113.49mm(4.468in)
Bore (in)4.468 in.
Bore (mm)113.487mm
Category HierarchyAccessories>Rings>Ring Sets
File FitNo
File FitYes
GaplessNo
IndustryAutomotive
NotesSingle piston set.
Oil Ring (Heigh/Width/Type)4.0mm / 0.130 / CUF
Oil Ring IncludedYes
Oil Ring MaterialChrome plated carbon steel
Oil Ring TensionLow
Oil Ring Tension Rating11-12 lb.
Oil Ring Thickness3/16 in.
Oil Ring Thickness0.158
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
QuantitySold as a set.
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate coated
Second Ring Facing MaterialPhosphate
Second Ring IncludedYes
Second Ring MaterialIron
Second Ring Thickness1/16 in.
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0787
Top Ring (Heigh/Width/Type)2.0mm / 0.208 / DMK
Top Ring Facing MaterialPhosphate coated
Top Ring Facing MaterialPlasma Moly
Top Ring IncludedYes
Top Ring MaterialIron
Top Ring MaterialDuctile iron
Top Ring Thickness1/16 in.
$61.99
PART NUMBER: J83001-4468
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.210 / IPT
Bore115.82mm(4.560in)
Bore (in)4.560 in.
Bore (mm)115.951mm
Bore Diameter4.560
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
GaplessNo
IndustryAutomotive
NotesSingle piston set. Barrel face D-wall torsional top ring, taper face D-wall reverse torsional second ring with SS50U-style oil ring.
Oil Ring (Heigh/Width/Type)3 / 16 / 0.190 / CUS
Oil Ring IncludedYes
Oil Ring MaterialChrome plated carbon steel
Oil Ring TensionHigh
Oil Ring Tension Rating23-24 lb.
Oil Ring Thickness3/16 in.
Oil Ring Thickness0.188
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
QuantitySold as a set.
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate coated
Second Ring Facing MaterialPhosphate
Second Ring IncludedYes
Second Ring MaterialIron
Second Ring Thickness1/16 in.
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.064
Top Ring (Heigh/Width/Type)1 / 16 / 0.210 / HPB
Top Ring Facing MaterialManganese
Top Ring Facing MaterialPhosphate
Top Ring IncludedYes
Top Ring MaterialDuctile iron
Top Ring MaterialHard Ductile Iron
Top Ring Thickness1/16 in.
$62.99
PART NUMBER: J820H1-4560-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore102.36 mm(4.030 in)
Bore Diameter4.030
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.152 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J75001-4030-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore105.54mm(4.155in)
Bore Diameter4.155
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.152 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$48.99
PART NUMBER: J75001-4155-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.5mm / 0.170 / IPE
Bore102.36 mm(4.030 in)
Bore Diameter4.030
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.146 / CUF
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0591
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.0472
Top Ring (Heigh/Width/Type)1.2mm / 0.145 / CMR
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialCarbon Steel
$51.99
PART NUMBER: J750F1-4030-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.193 / IPG
Bore104.65mm(4.120in)
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3 / 16 / 0.150 / CUF
Oil Ring Thickness0.188
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.064
Top Ring (Heigh/Width/Type)1 / 16 / 0.192 / DMB
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialDuctile iron
$45.99
PART NUMBER: J50001-4120-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.193 / IPG
Bore104.90mm(4.130in)
Bore Diameter4.130
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3 / 16 / 0.190 / CUS
Oil Ring Thickness0.188
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.064
Top Ring (Heigh/Width/Type)1 / 16 / 0.193 / DMB
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialDuctile iron
$45.99
PART NUMBER: J500F1-4130-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1.75mm / 0.165 / IPE
Bore100.00 mm(3.937 in)
Bore Diameter3.937
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3.0mm / 0.150 / IPD
Oil Ring Thickness0.118
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.0689
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialIron
Third Ring MaterialIron
Top Compression Ring Thickness0.0591
Top Ring (Heigh/Width/Type)1.5mm / 0.165 / IPA
Top Ring Facing MaterialPhosphate
Top Ring MaterialIron
$69.99
PART NUMBER: J660U1-3937
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.187 / IPG
Bore102.11 mm(4.020 in)
Bore Diameter4.020
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3 / 16 / 0.190 / CUS
Oil Ring Thickness0.188
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.064
Top Ring (Heigh/Width/Type)1 / 16 / 0.187 / DMB
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialDuctile iron
$63.23
PART NUMBER: J500F1-4020-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.187 / IPG
Bore102.36 mm(4.030 in)
Bore Diameter4.030
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3 / 16 / 0.190 / CUS
Oil Ring Thickness0.188
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.064
Top Ring (Heigh/Width/Type)1 / 16 / 0.187 / DMB
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialDuctile iron
$63.23
PART NUMBER: J500F1-4030-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.187 / IPG
Bore102.62mm(4.040in)
Bore Diameter4.040
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3 / 16 / 0.190 / CUS
Oil Ring Thickness0.188
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.064
Top Ring (Heigh/Width/Type)1 / 16 / 0.187 / DMB
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialDuctile iron
$48.99
PART NUMBER: J500F1-4040-5
Ships from manufacturer
Description
Specifications
2nd Ring (Heigh/Width/Type)1 / 16 / 0.187 / IPG
Bore103.12mm(4.060in)
Bore Diameter4.060
Category HierarchyAccessories>Rings>Ring Sets
File FitYes
IndustryAutomotive
Oil Ring (Heigh/Width/Type)3 / 16 / 0.190 / CUS
Oil Ring Thickness0.188
Out of Stock MessageCall for Availability
Prop 65 (C, R or CR)CR
Prop 65 Yes/NoYes
Second Compression Ring Thickness0.064
Second Ring Facing MaterialPhosphate
Second Ring MaterialIron
Third Ring Facing MaterialCarbon Steel
Third Ring MaterialCarbon Steel
Top Compression Ring Thickness0.064
Top Ring (Heigh/Width/Type)1 / 16 / 0.187 / DMB
Top Ring Facing MaterialPlasma Moly
Top Ring MaterialDuctile iron
$63.23
PART NUMBER: J500F1-4060-5
Ships from manufacturer
Per page

Select & Customize

The experience was good except shipping website states if merchandise is in stock and ordered before 1pm ships that day, or after 1pm will be next business day, I ordered my tires on Sunday after 1pm and website states they are in stock but my order did not ship until Tuesday.

Good work

it is my first .... buy them I hope they are effective thanks

My only comment is the shipping costs are excessive!

Need a comment section on the order page. Other than that, hopefully I will get those tires here before Christmas.

Share icon
Return Policy
Returns are easy at THMotorsports

Not happy with a purchase? No problem. We've made returning items as easy as possible. And most purchases can be returned for free for 30 days. Learn more about our Returns Policy
