Bosch 156-153-00-28 Fuel Rail Pressure Sensor

The Bosch 156-153-00-28 is a precision-engineered fuel rail pressure sensor designed to monitor and regulate fuel pressure in modern fuel injection systems. This sensor mounts directly on the fuel rail and continuously reads high-pressure fuel, relaying critical pressure data back to the vehicle's engine control module (ECM) for optimal fuel delivery management.

Key Features:

• Precision pressure measurement using silicon membrane resistance bridge technology
• Fast response time for real-time fuel pressure monitoring
• Sturdy construction with vibration resistance and thermal stability
• Built-in circuit protection to safeguard vehicle electronics
• OE-quality manufacturing to exact specifications

The sensor works by measuring pressure variations through a resistance bridge that evaluates the distortion of a silicon membrane. This data allows the ECM to dynamically adjust fuel pressure based on engine RPM, load, speed, and demand for maximum performance and efficiency. Bosch fuel pressure sensors are proven reliable in both gasoline and diesel direct injection systems.

Cross-Reference Part Numbers: Bosch 0-261-230-137, 0261230137, Mercedes-Benz 1561530028, A1561530028, Standard Motor Products FPS75
