McLeod 681622-00-10 Mag Force Double Disc Steel Racing Clutch Kit – Pin Drive, 1" x 24 Spline

Manufacturer

Part Number

681622-00-10
Black Friday Price

$1,585.00

Estimated ship date Saturday, December 05

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The McLeod Mag Force Double Disc Racing Clutch Kit (PN 681622-00-10) is a purpose-built, high-torque racing clutch designed for Nissan SR-20 rear-wheel-drive applications from 1989–2002. Engineered for serious motorsport competition, this steel disc, pin-drive unit delivers the lightweight construction and extreme torque capacity that demanding race environments require.

The Mag Force double disc configuration is rated at 900 ft-lb of torque capacity, making it an ideal step up from a single-disc setup for high-horsepower builds without the added complexity of a triple disc. The clutch features a 1" x 24-spline input shaft fitment and a 0-balance (neutral balance) specification, meaning no external balance weights are required for this application.

Key Features:

  • Double disc steel construction – provides 900 ft-lb torque capacity in a compact, lightweight package
  • Pin drive actuation system – floater plate slides on 6 evenly spaced pins for fast, consistent clutch release in racing conditions
  • Lightweight design – reduces rotating mass for improved throttle response and drivetrain performance
  • 0-balance specification – neutral balance for direct bolt-on fitment without additional balancing hardware
  • 1" x 24-spline input – correct fitment for compatible Nissan SR-20 RWD transmissions (1989–2002)
  • Bolt-on external balance weight provision – available on applicable Mag Force units for versatility across platforms
  • Suited for oval track, road racing, and dry lakes competition use

McLeod Racing is an industry leader in performance clutch technology, and the Mag Force line represents their top-tier racing clutch offering. The Mag Force series is offered in single disc (500 ft-lb), double disc (900 ft-lb), and triple disc (1,500 ft-lb) configurations to match a wide range of power levels and racing disciplines.

Products specifications

Hub Style

Solid

Ring Gear

Factory

Engine Balance

Neutral

Make

NISSAN

Number of Discs

Double

Clutch Patterns

Proprietery McLeod Mag Force

Hardware Included

Yes

Flywheel Material

Aluminum

Throwout Bearing Style

Standard

Engine

SR20DE/DET 2.0L

Spline

1 x 24

Disc Material

Sintered iron

Disc Style

Segmented

Torque Rating

900 Ft. lbs.

Throwout Bearing Included

No

Alignment Tool Included

Yes

Pressure Plate Style

Diaphragm

Disc Diameter

8In.

Clutch Usage

Drifting,Land Speed, Road Race

Flywheel Included

Yes

Pilot Bushing Included

No
