Edelbrock 60549 RPM Big-Block Chevy Rectangular Port Cylinder Head

(Chevrolet Corvette 1970-74, Impala 1970-76, Malibu 1973-75, C1500 1990-93, Chevelle 1970-73, Blazer 1973-74, C10 Pickup 1973-74 + 99 more models)

Manufacturer

Picture for manufacturer Edelbrock

Part Number

60549
6 reviews
Sale Price

$858.48

In Stock (10+)

delivery box

Usually delivered within 2 days

Check out with

ApplePay
Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Edelbrock 60549 Performer RPM bare cylinder head is engineered for high-performance Big-Block Chevy applications with rectangular port design. Manufactured from A356 aluminum and made in the USA, this cylinder head is ideal for street performance vehicles, daily drivers, street rods, and muscle cars where responsive power delivery is essential.

Performance Characteristics:

Delivers great throttle response and power from 1500 to 6500 rpm, making it perfect for street and high-performance applications operating between 2500-7000 rpm. These cylinder heads offer out-of-the-box bolt-on performance with no additional porting required.

Technical Specifications:

  • Combustion chamber volume: 118cc
  • Intake runner volume: 315cc
  • Exhaust runner volume: 110cc
  • Intake valve diameter: 2.19 inches
  • Exhaust valve diameter: 1.88 inches
  • Valve stem diameter: 11/32 inch
  • Manganese bronze valve guides
  • Deck thickness: 9/16 inch
  • Valve spring maximum lift: 0.700 inch
  • Rocker stud: 7/16 inch
  • Pushrod diameter: 3/8 inch
  • Valve angle: 26 degrees
  • Spark plug fitment: 14mm x 3/4 inch reach, gasket seat

Important Installation Notes:

Bare heads will have valve guides and seats installed, but will require final sizing and a valve job to match the valves you will be using. Spark plug is closer to center of bore and will interfere with high-dome pistons—use pistons designed for these heads. Match with Edelbrock head gasket sets.

Emissions Notice:

For use on pre-pollution controlled vehicles only.

Sold individually. Compatible with Big-Block Chevy 396, 402, 427, and 454 cubic inch engines with rectangular port intake manifolds.

Products specifications

Fits

Chevrolet Corvette 1970-74, Impala 1970-76, Malibu 1973-75, C1500 1990-93, Chevelle 1970-73, Blazer 1973-74, C10 Pickup 1973-74, Caprice 1970-76, C10 1975-80, El Camino 1970-75, Monte Carlo 1970-75, K2500 1991-95, Nova 1970-71 + 93 more models

Series

Performer RPM

Retainer Included

No

Seat Angle

Exhaust 45 deg/Intake 45

EGR Port

No

Grade Type

Performance

Seat Material

Ductile Iron

Guide Material

Manganese Bronze

Deck Thickness

0.5625

Quantity

Sold individually

Exhaust Runner Volume

110

CNC Ported

No

Construction Type

Bare

Valve Included

No

Exhaust Port Location

Standard

RGL

WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.

Family

Performer RPM

Material

Aluminum

Valve Springs Included

No

Guide Plates Included

No

Combustion Chamber Volume

118

Intake Runner Volume

315
