GReddy 12040722 V-Mount Type-19 Intercooler Radiator Kit Version 2

Manufacturer

Part Number

12040722
Sale Price

$3,012.53

Estimated ship date Sunday, November 29

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The GReddy 12040722 is a Version 2 V-Mount Intercooler and Radiator Kit designed for late-model Mazda RX-7 FD3S applications. Originally engineered for drag racing setups, this complete cooling solution has become equally popular with circuit track cars running aero hoods, providing exceptional cooling performance through innovative V-mount configuration.

Type-19 Intercooler Core Specifications:

  • Lightweight tube and inner-fin 3-row air-to-air core construction
  • Core dimensions: 400mm L x 266mm H x 100mm W (15.7" x 10.5" x 3.9")
  • High-flow cast aluminum end tanks
  • Includes cast aluminum GReddy 13B-REW compression pipe

TWR Racing Radiator:

  • Full aluminum construction with high-performance 2-row core
  • Radiator dimensions: 631mm L x 355mm H x 48mm W (24.8" x 14.0" x 1.9")
  • Heavy-duty aluminum end tanks with pre-drilled 1/8 BSP port for aftermarket temperature probe
  • Maintains factory mounting points, fan shroud, cap and connection points for straightforward installation

V-Mount Configuration Benefits:

  • Specially designed bracketry mounts both coolers in optimal "V" orientation
  • Favors engine cooling for the radiator while maintaining excellent airflow to intercooler
  • Minimizes intercooler piping length for improved turbo response
  • Includes air diversion panels to direct airflow from front bumper opening to both heat exchangers

Complete Kit Includes:

  • Type-19 Intercooler with cast end tanks
  • TWR aluminum radiator
  • Cast aluminum compression tube for 13B-REW
  • Two turbo elbows with model-specific cast elbow for turbo outlet
  • Complete intercooler piping system
  • Suction kit with two strategically-located Airinx S open-air intake filters
  • Power steering cooler modification system
  • Air guide plates for radiator and intercooler
  • All necessary mounting hardware and brackets

Important Note: This Version 2 kit (part number 12040722) does NOT include the GReddy Radiator Breather Tank, which is sold separately. This kit is designed for factory turbo applications on late-model "Kouki" FD3S models and features piping layout optimized for aero bonnet installations.
