Manley 561110CE-8 Platinum Series Forged Piston Set - Chevy 5.3L LS Gen III 3.790 Bore

The Manley 561110CE-8 is a high-performance forged piston set designed for Chevrolet 5.3L LS Gen III engines, featuring a 3.790-inch bore diameter and 1.115-inch compression height. This complete set includes 8 pistons with all necessary hardware for a professional engine build.

Key Specifications:

• Bore Size: 3.790 inches
• Compression Height: 1.115 inches
• Dome Volume: -7cc (dish)
• Piston Pin Diameter: .927 inches
• Compatible Rod Length: 6.125 inches
• Stroke: 4.000 inches
• Weight: 402 grams (nominal)

Platinum Series Features:

• 2618 alloy forgings for superior strength and performance
• Premium chrome moly wrist pins included
• Cam and barrel skirt profiles that generate substantial power while being gentle on cylinder walls
• Exacting ring lands and grooves for enhanced ring seal and more power
• Unique fixturing for ultimate ring groove to skirt squareness
• Moly skirt coatings for reduced friction
• Round wire locks included

Trusted by professional engine builders and tuners worldwide, Manley pistons deliver superior performance and durability for high-performance LS engine builds.
