MAHLE 930205596-1 Small Block Chevy 305ci Flat Top Forged Piston 3.796 Bore 4032 Alloy

Manufacturer

Part Number

930205596-1
Black Friday Price

$118.01

Estimated ship date Saturday, December 05

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The MAHLE 930205596-1 is a single forged flat top piston engineered for Small Block Chevy 305ci performance and racing builds. Machined from 4032 aluminum alloy, this PowerPak piston delivers superior temperature stability and allows for tighter piston-to-wall clearances compared to traditional cast pistons.

This piston features a slipper skirt forging design that reduces reciprocating mass while maintaining structural integrity under high-stress conditions. The gas-ported crown with asymmetrical valve pockets enhances ring seal and combustion efficiency, making it a proven choice for dirt track and performance street builds.

Performance Coatings:

  • Grafal® Anti-Friction Skirt Coating — reduces drag, scuffing, friction, and cylinder bore wear while minimizing piston noise
  • Phosphate Dry Lubricant Coating — protects pin bores and ring grooves against galling and microwelding during initial startup and engine break-in

Specifications:

  • Bore Diameter: 3.796 in (+0.060 over)
  • Compression Height: 1.550 in
  • Stroke: 3.480 in
  • Rod Length: 5.700 in
  • Pin Diameter: 0.927 in
  • Dome/Dish Volume: -1.6cc (flat top)
  • Piston Weight: 421 g
  • Compression Ratio: 9.9:1 (at zero deck with 0.040 in gasket)
  • Alloy: 4032 Aluminum
  • Ring Groove: 1.0 x 1.0 x 2.0 mm (file fit performance ring set)
  • Wrist Pin Weight: 92 g (lightweight)

Sold as a single piston. CNC-machined pin bores and ultra-flat ring grooves ensure optimal ring seal and long-term durability. The machineable piston crown allows for custom combustion chamber work when required.

Products specifications

Piston Mass

421g

Prop 65

WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov

Piston Ring Thickness

1.0mm, 1.0mm, 2.0mm

Piston Material

Forged, 4032

Pin Style

Floating

Pin Material

Steel

Clip Style

Round Wire
