King Engine Bearings CR509XPC XP-Series Coated Connecting Rod Bearing Set

(1999 Volvo S80 2.9; 2004, 2006-2007 Volvo V70 2.4; 1992-1997 Volvo 960 Base; 1997-1998 Volvo S90 Base; 1993 Volvo 850 GLT; 2004-2005 Volvo S40 i + 4 more models)

Manufacturer

Part Number

CR509XPC
Black Friday Price

$142.60

Estimated ship date Thursday, December 10

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

King Engine Bearings CR509XPC Connecting Rod Bearing Set

The King Engine Bearings CR509XPC is a high-performance connecting rod bearing set featuring advanced XPC Series technology with pMaxKote nano-composite polymer coating. Designed for demanding performance applications, these bearings deliver superior protection and durability under extreme engine loads.

XPC Series pMaxKote Technology

The XPC designation indicates these bearings feature King's proprietary pMaxKote nano-composite polymer coating applied over the pMaxBlack tri-metal overlay. This factory-applied coating enhances wear resistance and seizure protection without adding any thickness to the bearing's precision dimensions. The coating contains ceramic nano-composite particles and solid lubricants that protect against metal-to-metal contact during periods of marginal lubrication.

Advanced Tri-Metal Construction

Built with King's enhanced tri-metal design, these connecting rod bearings layer copper-lead construction with a nickel plate barrier and a lead/tin/copper Babbitt overlay over a steel backing. The proprietary SecureBond adhesion process provides 24% stronger overlay and 17% greater fatigue resistance compared to conventional tri-metal bearings. This construction delivers superior stability and durability for high-load performance applications.

Precision Manufacturing

King maintains industry-leading wall thickness tolerances of ±0.0001 inch through their "Bull's Eye" quality control process, ensuring consistent bearing clearances and optimal fit. The bearings feature precisely controlled crush height for improved bearing-to-bore contact, enhanced heat transfer, and reduced spin potential in high-RPM applications.

Key Features

  • Factory-applied pMaxKote nano-composite polymer coating for enhanced wear resistance
  • Superior seizure and cavitation resistance
  • Protection during oil starvation conditions
  • Tri-metal construction with SecureBond adhesion technology
  • Ultra-tight wall thickness tolerance of ±0.0001 inch
  • 24% stronger overlay than conventional tri-metal bearings
  • 17% greater fatigue strength
  • Ideal for performance street and racing applications
  • Compatible with forged steel aftermarket crankshafts

Applications

King XP-Series bearings are engineered for high-performance and racing applications that produce high loads for extended periods. The pMaxKote coating provides additional protection for extreme performance builds, turbocharged engines, and applications with elevated cylinder pressures.

Note: Verify fitment for your specific engine application. Professional installation recommended. Proper bearing clearances must be measured and verified during installation.

Products specifications

Fits

1999 Volvo S80 2.9; 2004, 2006-2007 Volvo V70 2.4; 1992-1997 Volvo 960 Base; 1997-1998 Volvo S90 Base; 1993 Volvo 850 GLT; 2004-2005 Volvo S40 i; 2006-2010 Volvo S40 2.4i; 2005 Volvo V50 i; 2006-2010 Volvo V50 2.4i; 1997-1998 Volvo V90 Base

Shaft UnderSize

STD

Housing Diameter

53.01 / 53.00 mm || 2.087 / 2.087 inch

STD Max Thickness

1.494

STD Shaft Diameter

50.00 / 49.98 mm || 1.969 / 1.968 inch

Material

Race Version TriMetal (pMax Black & Polymer)
