King Engine Bearings CR6629XPSTDX XP-Series Connecting Rod Bearing Set STDX

(Hyundai Sonata 1995-98; Mitsubishi Eclipse 2000, Montero 1994-96, Galant 1988, 2002-03, Diamante 1996, Sigma 1989-90 + 12 more models)

Manufacturer

Part Number

CR6629XPSTDX
Black Friday Price

$112.21

Estimated ship date Friday, December 11

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

King Engine Bearings CR6629XPSTDX Performance Connecting Rod Bearing Set

The King Engine Bearings CR6629XPSTDX is a high-performance XP-Series connecting rod bearing set engineered for demanding performance applications. These race-proven bearings feature King's advanced tri-metal construction and STDX sizing, which provides standard dimensions with an additional 0.001-inch clearance for optimal oil flow and performance tuning.

Advanced XP-Series Construction

King's XP-Series bearings utilize enhanced tri-metal copper-lead construction with a nickel plate barrier and lead/tin/copper Babbitt overlay bonded to a steel backing. The proprietary pMax Black™ overlay is 24% harder than conventional tri-metal race bearings, delivering superior load capacity of up to 17,000 psi in the intermediate layer and exceptional fatigue resistance. The unique SecureBond adhesion process ensures superior stability between layers for extreme performance applications.

Precision Engineering Features

These connecting rod bearings showcase King's legendary "Bull's Eye" tolerance control, maintaining wall thickness tolerances at an incredibly tight ±0.0001 inch—far exceeding industry standards. This precision ensures consistent bearing-to-bearing dimensions and predictable oil clearances during assembly. The XP-Series design includes increased crush height for improved bearing-to-bore contact and enhanced heat transfer, plus medium eccentricity for optimum load distribution.

Performance Application

Developed specifically for high-performance and racing applications using forged steel aftermarket crankshafts, the CR6629XPSTDX bearing set handles extreme loads for extended periods. The STDX designation indicates these bearings are sized for standard crankshaft journals with an additional 0.0005-inch clearance over true standard size, making them ideal for performance builds requiring slightly more oil clearance.

King Engine Bearings Quality

Founded in 1960, King Engine Bearings specializes exclusively in engine bearings, producing the highest quality bearings available in the automotive aftermarket. Every bearing undergoes rigorous quality control throughout the manufacturing process, all completed under one roof. King's race-proven technology is trusted by professional engine builders worldwide for both competition engines and high-performance street applications.

Products specifications

Fits

Hyundai Sonata 1995-98; Mitsubishi Eclipse 2000, Montero 1994-96, Galant 1988, 2002-03, Diamante 1996, Sigma 1989-90; Dodge Grand Caravan 1987-88, 1993-95, Avenger 1995, Stratus 1999-2001, Daytona 1993, Dynasty 1989 + 7 more models

STD Max Thickness

1.488

Shaft UnderSize

STDX

Housing Diameter

53.02 / 53.00 mm || 2.087 / 2.087 inch

STD Shaft Diameter

50.00 / 49.97 mm || 1.969 / 1.967 inch

Material

Race Version TriMetal (pMax Black)
