Manley 696530-8 Forged Inverted Dome Piston Set Big Block Chevy 4.530 Bore

Manufacturer

Part Number

696530-8
Black Friday Price

$918.98

Estimated ship date Saturday, December 05

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Manley 696530-8 is a high-performance forged inverted dome piston set designed for Big Block Chevrolet racing applications. Engineered from 2618 high-strength aluminum alloy, these pistons deliver exceptional durability and resistance to extreme temperatures and forces, making them ideal for drag racing and high-horsepower builds.

Key Features:

  • 4.530" bore diameter for aftermarket Big Block Chevy blocks
  • Forged from 2618 high-strength aluminum alloy for maximum fatigue resistance
  • Inverted dome design for optimal combustion chamber geometry
  • Lightweight construction for reduced reciprocating mass
  • Full banded skirt design for increased skirt stability
  • Perfect ring groove to skirt squareness for maximum sealing efficiency
  • Lateral gas ports included for improved ring seal
  • Round wire locks included
  • .043" x .043" x 3/16" ring package configuration

Each set includes eight pistons complete with wrist pins and locks. Manley's precision machining and proprietary multi-step ring groove process ensures optimal combustion sealing and long-term reliability in demanding racing environments. These pistons are specifically designed for drag racing and other high-performance applications where maximum strength and durability are critical.

Products specifications

Bore (in)

4.530 in.

Bore (mm)

115.062mm

Calculator

Compression Calculator

Compression Distance (in)

1.395 in.

Notes

0.300 in. intake valve relief. Groove lock spacer included.

Pin Diameter (in)

0.990 in.

Piston Head Volume (cc)

+10.00cc

Piston Material

Forged aluminum

Piston Ring Thickness

1/16 in. x 1/16 in. x 3/16 in.

Piston Style

Dish, with a D-shaped cup

Quantity

Sold as a set of 8.

Tool

Stroker Combinations

Wrist Pin Style

Press-fit or floating

Piston Quantity

8

Make

Chevrolet

Bore Diameter

4.530

Compression Height

1.395

Engine Type

ICE

Engine

Big Block

Product Type

Engine Piston Kit

Piston Volume

-10.00

Piston Series

Platinum Series

Weight

660

Title

Manley Piston Set, PIST-4.530/1.395/ID
