JE Pistons 345871L Ford Modular FSR Forged Piston Single 3.701 Bore 2618 Alloy Dome Left

Manufacturer

Part Number

345871L
Sale Price

$187.99

Estimated ship date Monday, November 16

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The JE Pistons 345871L is a high-performance forged single piston (left) engineered for the Ford Modular platform. Built from 2618 aluminum alloy, this dome-profile piston features JE's proprietary Forged Side Relief (FSR) forging architecture, purpose-built to handle the demands of high-horsepower street and race engine builds.

Key Features:

  • Alloy: 2618 wrought aluminum — the preferred material for forced induction and high-stress performance applications
  • Forging Design: FSR (Forged Side Relief) — reduces skirt width to minimize friction and saves weight via a shorter wrist pin boss, while adding material where strength is critical
  • Crown Profile: Dome
  • Bore Diameter: 3.701 in.
  • Compression Height (CD): 1.161 in.
  • Pin Diameter: 0.827 in.
  • Ring Groove Compatibility: Machined for modern 1.0mm / 1.2mm / 2.8mm and 1.2mm / 1.5mm / 3.0mm ring packages
  • Quantity: Single piston (Left)

JE Pistons are engineered, forged, and machined 100% in the USA, with each piston designed for its specific engine and racing application to deliver an optimal balance of durability and performance. With over 75 years of experience producing championship-winning forged pistons, JE is a trusted name among professional engine builders and race teams worldwide.

Products specifications

Category Hierarchy

Pistons>Individual Pistons

Cylinder Head

MODULAR 5.2L VOODOO

Engine

MODULAR FORD

Piston Volume

8.9

Piston Head Type

Dome

Out of Stock Message

Call for Availability

Forging Type

FSR

Industry

Automotive

Top Compression Ring Thickness

0.04

Add-On

827-2250-15-51C

Piston Pin Length

2.250

Bore Diameter

3.701

Add-On

JG1001-3701

Add-On

827-063-MW

Compression Height

1.161

Oil Ring Thickness

0.111

Ringset Included

Yes

Product Market

Domestic

Piston Pin Wall Thickness

0.150

Piston Avg Wt

398

Piston Pin Outside Diameter

0.827

Second Compression Ring Thickness

0.048

Piston Pin Material

5115

Piston Material

2618

Make

Ford
