Wiseco K397X135 Professional Series Forged Piston Kit 4.135" Bore Chevy LS

Manufacturer

Part Number

K397X135
Black Friday Price

$1,142.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco K397X135 Professional Series Piston Kit is a premium forged piston set engineered for high-performance Chevrolet LS engine builds. This complete 8-piston kit features a 4.135-inch bore diameter and is designed for 4.000-inch stroke applications with 6.098-inch connecting rods, making it ideal for stroker builds and serious performance applications.

Key Features:

  • Flat-top piston design with two valve reliefs for optimal combustion and valve clearance
  • ArmorGlide skirt coating reduces friction, maximizes horsepower, and improves wear resistance
  • Accommodates reluctor ring on stroker cranks without notching pin bosses
  • Offset pins and OE-style skirt shapes specifically designed for street applications
  • Anti-detonation and pressure seal grooves for improved ring seal and reduced piston noise
  • Successfully tested in the highest horsepower applications
  • Precision-engineered for tighter piston-to-bore clearances than non-coated pistons
  • Piston rings for all cylinders
  • Wrist pins and circlips

Wiseco Professional Series pistons represent the pinnacle of piston technology, combining advanced forging processes with precision CNC machining. These pistons are manufactured in Wiseco's facility using aerospace-grade aluminum alloy and are proven in racing applications requiring over 1,500 horsepower. The forced pin oiling design ensures proper lubrication while the pressure seal grooves minimize blow-by for maximum performance and efficiency.

Products specifications

Piston Quantity

8

Rod Length

6.125

Stroke

4.000

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Engine

LS

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.135

Compression Height

1.115

Industry

Automotive

Product Market

Domestic

Engine Type

ICE

Wrist Pin Material

5115

Product Series

Professional

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Second Compression Ring Thickness

1.2

Top Compression Ring Thickness

1.2

EBAY Category ID

33623

Engine - Web

LS

Make - Web

Chevrolet

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Oil Ring Thickness

2.0

Piston Volume

-32.00

Title

Wiseco - Chevrolet, LS, 4.135 in. Bore, Piston Set of 8

Title - Web

Professional Chevy LS Piston Set of 8 - 4.135 in. Bore - 1.115 .in CH, -32.00 CC
