Brembo 09.D094.13 UV Coated Two-Piece Vented Disc Brake Rotor 348mm Front Left

The Brembo 09.D094.13 is a premium two-piece composite disc brake rotor designed for front left installation. This high-performance rotor features a 348mm diameter with 36mm thickness and utilizes Brembo's advanced UV coating technology for superior corrosion protection and long-lasting performance.

Advanced Two-Piece Construction:

• Cast iron braking surface paired with aluminum or steel hub for optimal weight reduction
• Pillar Vented Technology (PVT) design increases air circulation and crack resistance by over 40%
• High carbon content cast iron minimizes noise and vibration while reducing cooling time
• Two-piece floating design prevents disc surface deformation under extreme heat

UV Coating Benefits:

• Environmentally friendly solvent-free coating protects entire disc surface
• Superior corrosion resistance that exceeds OEM standards
• Maintains clean aesthetic appearance throughout service life
• ECE-R90 certified quality assurance

Key Specifications:

• Diameter: 348mm (13.7 inches)
• Thickness: 36mm with minimum thickness of 34.4mm
• Height: 66mm
• 5-lug bolt pattern with 67mm centering
• Position: Front left axle
• Includes fixing screw kit for complete installation

OEM Replacement: This rotor meets or exceeds original equipment specifications and replaces BMW OE# 34116860911 and Toyota OE# 43516WAA01. Intelligent marking location shows part number and minimum thickness for easy inspection. For optimal braking performance, Brembo recommends replacing rotors and pads together and pairing with Brembo NAO/Ceramic or Low-Met brake pad formulations.
