Diode Dynamics DD2048 HD LED Halo Rings 70mm Red Pair

The Diode Dynamics DD2048 is a pair of 70mm red HD LED halo rings built using Diode Dynamics' proprietary HDHalo Technology. Each ring is populated with a high density of LED chips coated in a diffusing gel, producing a perfectly uniform, solid appearance when illuminated. When off, the gel conceals the individual LED chips for a clean, factory-like look.

These halo rings feature fully waterproof multi-function PWM drivers with three wiring inputs — low power, high power, and a turn signal/signaling mode — allowing direct integration as a multi-function lamp with no external controllers or dimmers required. The red color makes them ideal for use as running and brake light accents inside headlight or taillight housings.

Key Features:

• Proprietary durable phosphor coating for a uniform, solid appearance
• Multi-function waterproof PWM drivers with low power, high power, and turn signal modes
• Extremely bright high-density LEDs visible even in direct sunlight
• Integrated mounting tabs for easy installation via adhesive or beading wire
• Mounting tabs can be removed with clippers or light sanding if needed
• Up to 20% of the ring can be trimmed with side-cutting snips and remain fully functional
• Assembled in the USA
• Tested to SAE and DOT photometric and environmental standards

Sizing: The 70mm size refers to the outside diameter. Ring width is 8mm, giving an inside diameter of 54mm. Total height is 4.5mm. All sizes are listed by outside diameter in millimeters.

Sold as a pair. Compatible with any headlight or taillight housing — these rings are universal in design, making them suitable for a wide range of custom lighting applications.
