Manley 595900C-8 Platinum Series Forged Piston Set Ford 5.0L Coyote 3.662" Bore

The Manley 595900C-8 Platinum Series Piston Set is engineered for high-performance Ford 5.0L Coyote V8 engines. This professional-grade forged piston set features a 3.662-inch bore, 1.165-inch compression height, 6.75cc dish design, and delivers a 12:1 compression ratio with a 22mm wrist pin. Built from domestic 2618 alloy forgings, these pistons provide exceptional high-temperature strength and fatigue resistance for demanding street and race applications.

Key Features:

• 2618 alloy forgings for superior strength and durability under extreme conditions
• Premium 4130 chrome moly wrist pins included with round wire locks
• Cam and barrel skirt profiles engineered for maximum power while protecting cylinder walls
• Precision ring groove to skirt squareness achieved through unique single-fixturing manufacturing
• Moly skirt coating for reduced friction and enhanced longevity
• Exacting ring lands and grooves for improved ring seal and increased horsepower
• Pressure balance groove included for optimal performance
• 1.2mm x 1.2mm x 3mm ring package (requires Manley-specific Total Seal rings)

Manley's proprietary manufacturing process ensures each piston meets strict tolerances for ring lands, grooves, and skirt profiles. The contour forgings provide an optimal balance between strength and weight without grain-interrupting internal milling. Trusted by professional engine builders and tuners worldwide, these Platinum Series pistons deliver trouble-free installation, excellent reliability, and maximum horsepower for your Ford Coyote build. Sold as a complete set of 8 pistons.
