Manley 595838C-8 Platinum Series Forged Piston Set Gen 3 Coyote 5.0L 3.700" Bore 11.0:1

The Manley 595838C-8 Platinum Series forged piston set is engineered specifically for 2018 and newer Ford Mustang GT Gen 3 Coyote 5.0L DOHC 4-valve engines. This high-performance piston set features a +1cc dome design with a 3.700-inch bore size, delivering an 11.0:1 compression ratio for increased power output and performance.

Key Features:

• Forged from domestic 2618 high-strength aluminum alloy for superior durability and heat resistance
• 3.700-inch bore diameter with +1cc dome configuration
• 11.0:1 compression ratio optimized for performance applications
• Premium Chrome Moly wrist pins included for reliable operation
• Proven cam and barrel skirt profiles for maximum power while protecting cylinder walls
• Moly-coated skirts for reduced friction and wear
• Unique single-fixturing manufacturing process ensures perfect ring groove to skirt squareness
• Precision-machined ring lands and grooves for enhanced ring seal and power
• Offset wrist pin design for quieter cold starts
• Pressure balance grooves and round wire locks included
• Compatible with 1.2mm, 1.2mm, 3mm Total Seal ring package

Each piston is manufactured using contour forgings that provide optimal strength-to-weight balance without grain-interrupting internal milling.
