Wiseco KE247M74 Forged Piston Kit Suzuki G13B 1.3L 16V 74mm Bore 8.5:1 Compression

The Wiseco KE247M74 is a high-performance forged piston kit designed for the Suzuki G13B 1.3L 16-valve engine, featuring a standard 74mm bore diameter and 8.5:1 compression ratio. Wiseco pistons are manufactured from high-silicon, low-expansion aluminum alloy forged in-house for superior strength, reduced weight, improved heat transfer, and extended service life.

Key Specifications:

• Bore: 74mm (2.913 inches) - Standard Size
• Stroke: 75.5mm (2.972 inches)
• Compression Ratio: 8.5:1
• Compression Height: 28.3mm (1.114 inches)
• Rod Length: 120mm (4.724 inches)
• Piston Pin: 19mm (.748 inch diameter) - Part Number S475
• Piston Weight: 224 grams
• Piston Rings: Part Number 2913XC (included)
• Dome Volume: -8cc

Performance Features:

• Advanced valve pocket design with complex dome and crown shapes for multivalve applications
• ArmorGlide® skirt coating reduces friction and noise while freeing up horsepower
• Steel nitride/napier ring package and optimized skirt profiles for enhanced durability
• Diamond-turned finish from CNC-controlled machining centers ensures perfect surface finish with no size variation

This complete piston kit includes pistons, rings, wrist pins, and circlips. Ideal for performance rebuilds and turbo applications on Suzuki Swift GTI and other G13B-equipped vehicles.
