ACL Bearings 7M2094HX-STD Race Series Main Bearing Set Ford Barra Inline-6 Standard Size

Manufacturer

Part Number

7M2094HX-STD
Black Friday Price

$122.14

Estimated ship date Thursday, December 10

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The ACL Bearings 7M2094HX-STD is a high-performance main bearing set engineered specifically for Ford 4.0L Barra inline-6 engines, including naturally aspirated and turbocharged variants. These Race Series bearings are designed for engine builders and enthusiasts who demand superior durability and performance beyond standard replacement bearings.

Key Features:

  • HX-designation provides 0.001" extra oil clearance on standard journals for optimized lubrication
  • F780 tri-metal bearing material for exceptional strength and wear resistance
  • Hardened steel backing improves bearing support and housing retention
  • High-strength overlay plate with reduced thickness for superior fatigue resistance
  • Elimination of flash plating on bearing backs enhances heat transfer and housing grip
  • 3/4 grooved design optimizes load-carrying surface area and oil flow
  • Increased eccentricity compensates for bore distortion at high RPM
  • Standard size (STD) fits non-machined crankshaft journals

Specifications:

  • Bearing Material: F780 tri-metal construction
  • Journal Size: Standard (67.481-67.505mm shaft diameter)
  • Housing Size: 71.517-71.541mm tunnel diameter
  • Oil Clearance Range: 0.031-0.087mm vertical clearance
  • Overall Length: 20.9mm (0.8228")
  • Wall Thickness at Crown: 1.986mm

ACL Race Series bearings have proven themselves in championship-winning engines across multiple motorsports disciplines, from drift racing to NASCAR and NHRA competitions. These bearings deliver the precision tolerances and advanced metallurgy required for high-RPM applications where standard bearings cannot survive.
