Weld Racing Wheels 70HB7050A22A RT-S S70 Forged Aluminum Front Wheel 17x5 Black Anodized

The Weld Racing RT-S S70 wheel combines iconic split 5-spoke styling with proven three-piece forged construction designed for street and strip applications. This 17x5 front wheel features a forged billet aluminum center welded to cold-forged rim shells, delivering exceptional strength-to-weight ratio for American muscle cars and high-performance vehicles.

Construction & Design:

• Three-piece modular forged wheel with welded assembly process
• Forged billet center with cold-forged aluminum rim shells
• Black anodized finish with machined contrast accents
• High pad mounting configuration for multi-piston brake caliper clearance
• Split 5-spoke design delivers classic Weld Racing styling

Specifications:

• Wheel Size: 17 inch diameter x 5 inch width
• Bolt Pattern: 5x4.50 inch (5x114.3mm)
• Backspacing: 2.20 inches
• Material: Forging-grade aluminum alloy
• Finish: Black anodized with machined accents

Important Installation Notes:

• Requires 60-degree conical seat lug nuts (M14 x 1.5 thread typical)
• Factory lug nuts will NOT fit properly - aftermarket conical lugs required
• High pad design provides clearance for upgraded brake systems
• Designed, engineered, and manufactured in Kansas City, Missouri

The RT-S S70 series is engineered for both street performance and drag strip use, featuring application-flexible design with multiple mounting pad heights to accommodate drum brakes and multi-piston opposed calipers. Each wheel is F.E.A. tested and undergoes in-house destructive testing to ensure safety and reliability under demanding conditions.
