Moroso 9867M Mag-Tune Spark Plug Wire Set 8mm SBC Small Block Chevy Under Header 90 Degree HEI

(GMC G2500 1979-95, K1500 1979-86, 1988-95, C1500 1979-86, 1988-95, K2500 1979-80, 1988-95, Jimmy 1974-91, C3500 1979-86, 1988-95 + 138 more models)

Manufacturer

Picture for manufacturer Moroso

Part Number

9867M
7 reviews
Sale Price

$39.87

In Stock (6)

delivery box

Usually delivered within 2 days

Check out with

ApplePay
Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Moroso 9867M Mag-Tune spark plug wire set features a conductive latex-coated, heavy-duty fiberglass core with a spiral-wound stainless nickel alloy conductor, specifically designed to be routed under headers on Small Block Chevy engines. These spark plug wires are fully tested to ensure secure termination, electrical conductivity, and dielectric strength.

Key Features:

  • Stainless nickel alloy wire wound 32 times per inch around a conductive latex-coated, heavy fiberglass core
  • Wire jacket made from two-layer EPDM for the best heat protection and highest dielectric strength
  • Layers separated by a fiberglass reinforcing braid for added pull strength
  • Moisture-resistant 100 percent silicone boots and snap-lock spark plug terminals
  • Wire resistance of 350 ohms per foot
  • Meets OEM radio frequency interference (RFI) requirements while operating at one-tenth the resistance of conventional carbon core conductors
  • 90 degree boots assembled on both ends and includes a 35-inch coil wire
  • Coil wire distributor end is unassembled with both male and female ends included

This unsleeved, pre-assembled wire set is ready for installation and designed for Small Block Chevy engines (262-400 cubic inches) with HEI distributors. The 8.0mm diameter wires come in black with black silicone boots. Perfect for under-header routing, these wires eliminate the frustration of custom wire assembly while delivering race-quality performance.

Products specifications

Fits

GMC G2500 1979-95, K1500 1979-86, 1988-95, C1500 1979-86, 1988-95, K2500 1979-80, 1988-95, Jimmy 1974-91, C3500 1979-86, 1988-95, K2500 Suburban 1979-86, 1992-95, K3500 1979-86, 1988-95, C15/C1500 Pickup 1974, C2500 1979, 1988-95 + 134 more models

Assembled

Yes

Coil Wire Included

Yes

Conductor Style

Spiral core

Diameter (mm)

8.00mm

Distributor Boot Color

Black

Distributor Boot Material

Silicone

Distributor Terminal Ends

Male/HEI

Notes

Designed to be routed under headers.

Quantity

Sold as a kit.

RFI Suppression

Yes

Spark Plug Boot Color

Black

Spark Plug Boot Ends

Two 90 degree

Spark Plug Boot Material

Silicone

Wire Color

Black
