Cusco 175 270 G20 Safety 21 8-Point Roll Cage Toyota Chaser JZX100

The Cusco 175 270 G20 is a Safety 21 series 8-point roll cage engineered specifically for the Toyota Chaser JZX100 (non-sunroof models). This competition-grade roll cage features an "around dash" design that routes the front bars around the dashboard rather than through it, preserving interior functionality while delivering maximum protection and chassis rigidity enhancement.

Construction and Materials:

• Constructed from cold drawn seamless carbon steel tubing for exceptional strength
• 40mm diameter piping throughout with 2.0mm wall thickness
• Exceeds JAF domestic safety regulations with 510N/mm² material strength rating
• Mounting plates: minimum 60cm² area with 2.6mm thickness
• Reinforcement plates: minimum 120cm² area with 3.2mm thickness
• Precision-bent tubing that meets competition safety standards

Performance Benefits:

• Dramatically improves chassis rigidity for enhanced handling and steering response
• Provides critical driver protection in racing and high-speed situations
• Strategic mounting positions at suspension bases and high-strength chassis points maximize body rigidity
• Front cage design maintains optimal driver visibility
• Designed from Cusco's extensive racing experience and track feedback

Configuration:

• 8-point bolt-in design for maximum structural integrity
• 2-passenger seating capacity configuration
• Around-dash (escape) front bar layout
• Compatible with JAF competition regulations
• Some Safety 21 models are FIA homologated (check specific sanctioning body requirements)

This roll cage is engineered for serious motorsports applications including circuit racing, time attack, and drift competition. The bolt-in design allows for installation without welding, though welded installation provides the ultimate in rigidity. Professional installation is strongly recommended, and padding must be added to any bars within occupant proximity per safety regulations.
