AutoMeter ST747 Solid State Fluid Pressure Sensor 150 PSI 10 Bar 1/8 NPT

The AutoMeter ST747 is a compact, solid-state pressure transducer designed to measure fluid pressures up to 10 BAR (150 PSIG) relative to current atmospheric pressure. Engineered for demanding motorsports applications, this sensor delivers excellent accuracy, repeatability, and durability across a wide operating temperature range.

Key Features:

• Solid-state pressure transducer with 150 PSIG / 10 BAR maximum pressure range
• Compatible with common automotive fluids including water, coolant, gasoline, ethanol, methanol, diesel, air, nitrous oxide, oil, and brake fluid
• Stainless steel construction for superior corrosion resistance and durability
• 1/8" NPT male thread fitting for easy installation
• Includes adapters for 1/8" BSPT and M10 connections
• Compact design ideal for tight engine bay installations
• Measures pressure relative to atmospheric pressure (gauge pressure)

This versatile pressure sensor is well-suited for monitoring fuel pressure, oil pressure, brake line pressure, nitrous pressure, and other critical fluid systems in performance and racing applications. The rugged stainless steel housing withstands harsh automotive environments while maintaining consistent, reliable readings.
