Cometic H1796SPB060S MLS Head Gasket Bore - 87mm 0.060 SR20DET

The Cometic H1796SPB060S is a Multi-Layer Steel (MLS) head gasket engineered specifically for Nissan SR20DE and SR20DET engines in rear-wheel drive applications. This high-performance gasket features an 87mm bore diameter with a compressed thickness of 0.060 inches (1.5mm), making it ideal for modified engines requiring additional clearance or reduced compression ratios.

Key Features:

• Multi-Layer Steel construction with three layers of stainless steel for superior strength and durability
• 87mm bore diameter accommodates overbored cylinders and high-performance pistons
• 0.060" (1.5mm) compressed thickness for increased piston-to-head clearance
• Outer layers embossed and coated with Viton rubber material on both sides
• Viton coating heat resistant to 482°F (250°C) for extreme sealing environments
• Variable uncoated stainless steel center layer for precise thickness control
• No re-torque required after initial installation
• Designed for both oil holes configuration (S13/S14/S15 RWD)
• Compatible with aluminum-to-aluminum and aluminum-to-cast iron combinations

Cometic MLS head gaskets are designed to withstand high boost turbo applications, extreme cylinder pressures, and harsh operating conditions. The advanced construction provides maximum sealing performance without the need for additional sealants, making them the preferred choice for performance builds, racing applications, and engine rebuilds. Proudly manufactured in the USA with premium materials for reliable performance in the most demanding motorsports environments.
