TEIN GSMB2-91AS3 Street Advance Z Coilover Kit - Mazda CX-5

Manufacturer

Part Number

GSMB2-91AS3
Black Friday Price

$952.73

Estimated ship date Tuesday, December 01

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

TEIN GSMB2-91AS3 Street Advance Z Coilover Kit

The TEIN Street Advance Z coilover kit represents the evolution of the popular Super Street coilover system, engineered to deliver an ideal balance of sporty handling and comfortable street driving. Designed specifically for the Mazda CX-5 (2012-2016), this performance suspension system features twin-tube internal construction and advanced damping technology for exceptional ride quality and vehicle control.

Key Features

  • 16-Way Damping Adjustment: Utilizes TEIN's innovative Advance Needle technology for precise damping force adjustments, providing noticeable changes in ride characteristics at each click position
  • Height Adjustable: Adjustable ride height via ZT-coated threaded sleeve system for lowering capability and stance customization
  • Twin-Tube Design: Proven internal construction delivers reliable performance and comfortable street characteristics
  • Shortened Shell Case: Optimized damper stroke length maintains proper suspension travel even at lowered ride heights
  • ZT Coating Protection: Abrasion-resistant and corrosion-resistant surface treatment on threaded adjustment sleeves protects against road debris and elements
  • EDFC Compatible: Fully compatible with TEIN's Electronic Damping Force Controller (sold separately) for real-time damping adjustments from the cockpit
  • Made in Japan: Manufactured in TEIN's Yokohama facility under strict quality control standards

Specifications

Front Suspension:

  • 16-Stage Damping Adjustment: Yes
  • Full-Length Adjustable: No
  • Mount Type: Standard
  • Vehicle Height Drop: -40mm (-1.57 inches)
  • Maximum Height Adjustment Range: -66mm to -30mm (-2.6" to -1.18")
  • Recommended Height Adjustment Range: -50mm to -30mm (-1.97" to -1.18")
  • Spring Rate: 6kg (336 lbs/in)

Rear Suspension:

  • 16-Stage Damping Adjustment: Yes
  • Full-Length Adjustable: No
  • Mount Type: Reinforced Rubber
  • Vehicle Height Drop: -35mm (-1.38 inches)
  • Maximum Height Adjustment Range: -63mm to -30mm (-2.48" to -1.18")
  • Recommended Height Adjustment Range: -45mm to -30mm (-1.77" to -1.18")
  • Spring Rate: 4.5kg (252 lbs/in)

Performance Benefits

The Street Advance Z coilover system transforms your Mazda CX-5's handling characteristics by reducing body roll, improving cornering stability, and providing a lower center of gravity. The 16-way damping adjustment allows you to fine-tune suspension characteristics from comfortable daily driving to spirited backroad runs. Updated internal components and external coatings enhance durability and extend product life compared to previous generations.

What's Included

  • Complete front coilover assemblies (pair)
  • Complete rear coilover assemblies (pair)
  • All necessary mounting hardware
  • Installation instructions

Note: This kit uses OEM top mounts and does not provide camber adjustment. Optional EDFC (Electronic Damping Force Controller) available separately for in-cabin damping adjustment. If installing EDFC motors, waterproof sealing with silicone is required for motor, cable, and coupling components.
