Cusco 175 270 B20 Safety 21 6-Point Roll Cage Around Dash JZX100

The Cusco 175 270 B20 is a Safety 21 series 6-point roll cage designed specifically for the Toyota Mark II and Chaser JZX100 chassis without sunroof. This professional-grade roll cage provides enhanced chassis rigidity and occupant protection while maintaining a 5-passenger seating capacity with its around-dash front design.

Construction and Specifications:

• Cold drawn seamless carbon steel construction for maximum strength
• 40mm diameter tubing with 2.0mm wall thickness throughout
• Mounting plates: 60cm² or larger with 2.6mm thickness
• Reinforcing plates: 120cm² or larger with 3.2mm thickness
• 6-point configuration for balanced rigidity and accessibility
• Around-dash front cage design preserves driver visibility
• Black finish as standard

Performance Benefits:

• Dramatically improves chassis rigidity for enhanced handling and steering response
• Provides critical safety protection in rollover situations and competition use
• Strategic mounting positions at suspension towers and high-strength chassis points
• Meets JAF (Japanese Automobile Federation) competition regulations
• Designed with racing heritage and real-world competition feedback

Cusco Safety 21 roll cages are engineered for both street and track use, featuring bolt-in installation with all necessary mounting hardware included. The around-dash configuration allows full 5-passenger capacity while providing substantially improved structural integrity over the factory chassis.
