Wilwood 120-14320-FS TC 6R Radial Mount Front Brake Caliper Left Hand Red

The Wilwood TC 6R Radial Mount Caliper represents a new generation of refinement in big brake technology, specifically engineered to handle the heavy loads of custom late model trucks and sport utility vehicles. This left-hand front mount caliper features six stainless steel pistons housed within a high-strength forged aluminum body, delivering exceptional stopping power with stylish aesthetics in a gloss red finish.

Advanced Engineering and Construction:

• Stress flow forged from premium grade billet aluminum alloy using FEA structural analysis to minimize weight while maximizing rigidity
• Expanded bridge radius accommodates 1.38" thick rotors up to 16" in diameter
• Six high-strength coated steel alloy cross-bridge bolts reinforce the body against deflection and separation under high pressure and heavy loads
• Steel insert plates protect bridges from wear and gouging caused by brake pad edges
• Lightweight design starting at just 8.66 pounds

High-Performance Piston System:

• Six thick-walled stainless steel pistons (1.88"/1.62" bore configuration) provide superior clamping efficiency and resist deflection under heavy loads
• Stainless steel construction resists corrosion and reduces heat transfer to caliper body, seals, and brake fluid
• Differential piston bore design derived from Wilwood racing technology distributes clamping pressure proportionately for balanced pad loading and even wear
• Piston bore volumes configured for compatibility with OE master cylinder and power boost systems

Premium Features:

• Rubber dampened fluid transfer tubes for smooth operation
• Recessed two-piece bleed screws for easy maintenance
• Bridge-mounted pad dampening springs reduce vibration, road rattle, and engagement harmonics that cause brake squeal
• Multi-process gloss red coating combines high-tech style with corrosion protection
• Radial mount design allows secure, precise attachment to factory spindle bosses using adapter brackets

This TC 6R caliper delivers race-proven technology and uncompromising performance for demanding truck and SUV brake upgrades, combining massive stopping power with refined engineering and custom appearance.
