Fox Racing Shocks 883-09-141 Factory Race Series External Bypass QAB Shock Pair - 3.0 Rear

The Fox Racing Shocks 3.0 Factory Race Series External Bypass QAB shock set delivers race-proven off-road performance without compromising everyday ride quality. These premium rear shocks are specifically engineered for 2017-2018 Ford F-150 Raptor applications with 0-2 inch lift configurations.

Key Features:

• External Bypass position-sensitive damping for progressive control through the entire stroke range
• Quick Adjust Bypass (QAB) knobs allow tool-free external adjustments with positive click detents for consistent left/right tuning
• External Cooling System (ECS2) with hard-anodized aluminum finned remote reservoir and Recirculating Reservoir Bridge for superior heat dissipation
• 3.0-inch steel body with proprietary zinc-plated coating for enhanced durability in harsh conditions
• Hard-anodized CNC-machined 6061-T6 billet aluminum high-flow race piston
• Viton seals provide low friction, low wear, and high temperature resistance
• 17-4 H900 stainless steel piston rods offer twice the strength of standard carbon steel rods
• Monotube design with spherical bearing eyelets on both upper and lower mounts
• Protective black boot included

Specifications:

• Extended Length: 31.15 inches
• Collapsed Length: 18.88 inches
• Travel: 12.27 inches
• Body Diameter: 3.0 inches
• Sold as a pair

These shocks bolt directly to factory mounting points and utilize the same race-winning technology found on championship off-road racing trucks. The external bypass tubes allow fluid to bypass the piston through regulated zones during initial travel, then progressively increase damping force as the shock moves through its stroke, eliminating harshness over whoops while maintaining high-speed control and preventing harsh bottom-outs.
