Cometic H3532SP2027S Toyota 2GR-FE V6 MLS Cylinder Head Gasket 3.779in Bore .027in RHS

The Cometic H3532SP2027S is a high-performance Multi-Layer Steel (MLS) cylinder head gasket designed for the Toyota 2GR-FE 3.5L V6 engine. This is the right-hand side (RHS) head gasket, featuring a 3.779-inch (96mm) bore and a compressed thickness of 0.027 inches, making it an excellent choice for mildly built or naturally aspirated applications requiring a thinner gasket for optimal compression ratio retention.

Key Features:

• MLS Construction: Comprised of three to five layers of stainless steel for superior strength, rebound, and corrosion resistance
• Viton Coating: Outer layers feature embossed stainless steel coated with Viton rubber, heat resistant to 482°F (250°C), providing a micro-seal against the head and block surface
• No Sealants Required: MLS design delivers maximum sealing performance without the need for additional gasket sealants
• Bore Size: 3.779 inches (96mm) — round bore shape
• Compressed Thickness: 0.027 inches
• Orientation: Right-Hand Side (RHS)
• Number of Layers: 3
• Compatible with Aluminum-to-Aluminum and Aluminum-to-Cast Iron block pairings
• Ideal for naturally aspirated and mild forced induction builds
• Proprietary high-temperature coatings and embossments conform load distribution across the sealing area, reducing bore distortion

Cometic MLS head gaskets are engineered for today's high-output engines and are a preferred upgrade over OEM gaskets for performance builds. The center shim layer is uncoated stainless steel, allowing for precise thickness control, while the Viton-coated outer layers meet the demands of harsh sealing environments and varied surface finishes. This gasket is sold individually as the right-hand side unit — a matching left-hand side gasket is available separately.
