FAST 1000-1610B XDi Sportsman Large Cap Distributor Small Block Ford Bronze Gear

The FAST XDi Sportsman Distributor (1000-1610B) is a race-proven, billet ignition distributor engineered for small block Ford Windsor engines. Built for oval track and high-performance applications, it delivers rock-solid timing accuracy across the full RPM range by using an advanced Hall-effect style trigger pickup — eliminating the magnetic pickup compensation (timing retard) associated with conventional pickups for stable ignition timing from idle to redline.

Key Features:

• Hall-Effect Trigger: Produces a clean, accurate trigger signal compatible with most CD ignition controls — no retard, no timing drift
• CNC-Machined Billet Housing: Precision-machined aluminum construction for durability and consistent performance
• Polished Stainless Steel Shaft: Supported by a sealed ball bearing at the top and a long bushing at the bottom for smooth, reliable rotation
• Minimized End Play: Tightly controlled shaft end play reduces timing variation and prevents premature gear wear
• Bronze Drive Gear: Suitable for use with roller camshafts commonly found in performance and race engine builds
• Large Ford-Style Cap: Large diameter distributor cap for improved wire routing and reduced cross-fire risk
• Locked Advance: No mechanical advance — timing is fully locked out for consistent, ignition-box-controlled timing
• Includes: High-quality distributor cap and rotor

Important: This distributor requires a compatible FAST Ignition Control (E6 or E7 series) for proper operation. It is not designed for use with standard points-style or standalone coil-and-condenser ignition systems.

The 1000-1610B is the bronze gear / large cap variant of the XDi Sportsman line, making it the ideal choice for small block Ford Windsor builds running roller camshafts where a large-diameter Ford-style cap is preferred.
