MAHLE 930244737 Piston Kit (ms Set Sbf 348ci 4.037in Bore 3.4in Stroke 5.4in Rod .927 Pin-6cc 10.1 Cr Set Of 8), 1 Pack

The MAHLE 930244737 forged piston kit is engineered for high-performance Small Block Ford engine builds displacing 348 cubic inches. This complete 8-piston set is designed for serious enthusiasts building stroker combinations with precise specifications for optimal power and reliability.

Engine Specifications:

• Bore: 4.037 inches
• Stroke: 3.400 inches
• Rod Length: 5.400 inches
• Compression Height: 1.090 inches
• Compression Ratio: 10.1:1
• Displacement: 348 cubic inches

Piston Features:

• Premium 4032 aluminum alloy forging for superior strength and thermal expansion control
• 0.927-inch wrist pin diameter for robust pin retention
• -6cc dome volume (negative dome/dish configuration)
• 404 gram piston weight for balanced rotating assembly
• Precision-machined ring grooves for optimal sealing

MAHLE pistons are manufactured to OEM tolerances with racing-grade materials, making them ideal for street performance, street/strip, and racing applications. Each piston is individually weight-matched within tight tolerances to ensure smooth operation and maximum engine life. This complete set includes all eight pistons required for your Small Block Ford build.
