MAHLE PS102-023 Piston and Cylinder Set 102mm Bore 11.4:1 Compression Porsche 993 RSR

Manufacturer

Part Number

PS102-023
Black Friday Price

$4,396.97

$4,808.88 Save 9%

In Stock (6)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The MAHLE PS102-023 is a high-performance piston and cylinder set designed for Porsche 993 RSR engine conversions from 3.6L to 3.8L displacement. This complete set of six cylinders and pistons features a 102mm bore diameter with 109mm cylinder sleeves and delivers an aggressive 11.4:1 compression ratio for maximum power output in racing applications.

Key Specifications:

  • 102mm bore diameter for increased displacement
  • 76.4mm stroke length
  • 11.4:1 compression ratio (based on 1.0mm deck clearance and 90cc head volume)
  • 127mm connecting rod length
  • 31.5mm compression height
  • 23mm wrist pin diameter
  • 38.1cc crown volume
  • 496 gram piston weight
  • 109mm machine-in cylinder sleeve design

Advanced Engineering Features:

  • Forged 2618 aluminum alloy pistons for superior strength and thermal stability
  • Phosphate dry film lubricant coating prevents galling in wrist pin bores and microwelding in ring grooves
  • Proprietary Grafal anti-friction coating on piston skirts reduces friction and wear
  • Deep valve pockets with symmetrical crown design for high-performance camshaft compatibility
  • Modern thin-wall piston rings provide improved bore conformity and reduced friction
  • Complete set includes pistons, rings, wrist pins, and retaining clips

Important Installation Notes:

  • Arrow mark on piston crown must point toward flywheel during assembly
  • Uses top ring #09299380 and middle ring #09299381
  • Requires 109mm case opening (machine-in installation)
  • Set of 6 cylinders and pistons (one complete engine set)

MAHLE Motorsports has been the trusted choice of top Porsche engine builders for decades, delivering OEM-quality components with race-proven performance. This RSR-specification piston and cylinder set is ideal for serious performance builds and racing applications where maximum power and reliability are essential.
