QA1 SG12-88 High-Misalignment Rod End Spacer 3/4" Bore Stainless Steel

The QA1 SG12-88 is a precision-machined high-misalignment rod end spacer designed to maximize articulation and linkage travel in suspension and steering systems. This specialized spacer reduces the effective bore size to allow for greater misalignment angles, making it ideal for applications requiring increased joint articulation.

Key Features:

• Precision-machined from 303 stainless steel for superior strength and corrosion resistance
• High-misalignment design allows up to 58 degrees of articulation
• 3/4 inch outer bore diameter with 1/2 inch inner diameter
• Total width of 1.875 inches (1-7/8")
• Length: 0.92 inches
• Compatible with WPB-T (size 14 & 16 only), AIB, SIB, and MIB spherical bearings and all inch rod ends

Application:

Rod end spacers are used when mounting brackets are wider than the rod end ball width. High-misalignment spacers continue the spherical diameter of the ball, allowing the edge of the Heim joint to rotate into the body for maximum articulation. This is essential for racing suspension systems, street rods, and custom linkage applications where extreme angles and unrestricted movement are required.

Sold individually. Made in the USA by QA1 Precision Products.
