ACL Bearings 6B8466H-.025 Race Series Rod Bearing Set Toyota 2GR-FE V6 .025mm Oversize

ACL Race Series performance engine bearings provide enhanced quality and higher bearing capacity for engine tuning and performance upgrades. The 6B8466H-.025 is a connecting rod bearing set designed for the Toyota 2GR-FE 3.5L V6 engine in .025mm oversize, featuring F781 bearing material with identical bearing halves.

Key Features:

• High strength overlay plate with reduced thickness for improved fatigue properties
• Hardened steel backs on all rod bearings to improve support of the bearing lining and assist with bearing retention
• Increased crush for improved bearing retention and elimination of flash plating to maximize heat transfer
• Increased eccentricity to compensate for bore distortion at high RPM
• Advanced material composition with improvements in dynamic thickness, heat conduction, and oil distribution

Technical Specifications:

• Bearing Size: .025mm Oversize
• Shaft Range: 52.98-53mm (2.0858-2.0866")
• Tunnel Range: 56-56.02mm (2.2047-2.2055")
• Overall Length: 15mm (0.5906")
• Wall at Crown: 1.49mm (0.0587")
• Vertical Oil Clearance: 0.036-0.093mm

ACL Race Series bearings are recognized as a premier brand throughout the motorsports world, with rod and main bearings used in race engines that have set records and won championships from sport compact drift racing to NASCAR, IHRA, and NHRA competitions. These performance bearings are designed for engines that will be revving higher than stock and experiencing more stress than factory specifications.
