Auto Meter ST8130-I Street Dash, Wht, 0-3-10.5k Rpm (psi, Deg. F, Mph)

Race Ready. Refined Road Manners. Ideal for both Rally and High Performance Street cars, the ST8130 not only retains all the ST8100 racing features but also meets street legal requirements. Replaces speedometer, tachometer, oil-pressure, water-temperature, fuel-level, voltmeter, oil-temperature odometer and trip meter functions. Each system is supplied complete with sensors (except fuel level), ready wired harness and manual. Ultra light-weight design utilising a carbon fibre composite housing. Compatible with all conventional & MSD ignition systems and engine types.

Displays: RPM, Road Speed, Odometer, Tripmeter, Oil Pressure, Oil Temperature, Water Temperature, Fuel Level, and Battery Voltage. Optional Fuel Pressure display with purchase of sensor separately.

Ideal for naturally aspirated track cars

Intelligent Alarm System. Inboard Alarm Light and Low Fuel Light with External Shift and Alarm light Outputs - 5 Stage External Sequential Shift Light Option

Sensors Included

Combination of Analog & Digital Display Types

Simultaneous display of up to 4 parameters

Optional Lap Time, Predictive Lap Display

Professional Wiring Loom with Military Connector

Sealed (IP67) Carbon Composite Casing

Street Dash

Dial Color : White

Lens Style : Flat, Clear

Bezel Color : Black

Bezel Style : Stack

Size (Standard) : 7.5"W x 4"H x 1-1/2"D

Outer Bezel Diameter : 4.075"H x 7.775"

Lighting Type : LED

Lighting Color : White

Pointer Color : Orange

Movement : Analog/Digital

Gauge Type : Analog/Digital
