Fabtech K4066DL 3" Crawler Long Arm Coilover Lift Kit with Dirt Logic Reservoirs for Jeep JK

(2007-2017 Jeep Wrangler; 2018 Jeep Wrangler JK)

Manufacturer

Part Number

K4066DL
Black Friday Price

$5,288.12

Estimated ship date Saturday, December 26

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Fabtech K4066DL Crawler Coilover System is a heavy-duty long arm lift kit engineered for serious off-road performance while maintaining exceptional on-road driving characteristics. This comprehensive system replaces all eight factory link arms with extended-length units designed for aggressive rock crawling and trail use.

Key Features:

  • High-mounted link arms on the frame rails maximize ground clearance and approach angles
  • Large link arms pivot on Fabtech 5 Ton Joints with lifetime warranty for durability and quiet operation
  • 1/4-inch thick steel track bar brackets (weld-on) provide the strongest possible relocation solution for proper roll center geometry
  • Bolt-on Dirt Logic 2.5 front coilovers with external reservoirs deliver outstanding high-speed damping and low-speed crawl control
  • Coilover mounting positioned directly over axle centerline prevents premature link arm bushing wear
  • Dual-rate coil springs maintain factory load capacity while providing smooth ride quality
  • Extended travel suspension design offers maximum articulation for technical rock crawling with excellent highway manners
  • Dirt Logic 2.25 rear shocks with reservoirs provide superior damping and fade resistance

Complete Kit Includes: Eight long arm links with mounting brackets, front coilover hoop kit, long-travel rear coil springs, front and rear track bar brackets, front and rear sway bar links, pitman arm, front and rear brake lines, emergency brake bracket, rear bump stop brackets, front Dirt Logic 2.5 coilovers with reservoirs, and rear Dirt Logic 2.25 shocks with reservoirs.

This system is specifically designed for 2007-2018 Jeep Wrangler JK 4-Door models and provides approximately 3 inches of lift height.

Products specifications

Fits

2007-2017 Jeep Wrangler; 2018 Jeep Wrangler JK
