ARP M10AF90-5 Small 12-Point Bolt from Head Stud Kit 230-4201 5-Pack

Manufacturer

Part Number

M10AF90-5
Black Friday Price

$4.75

$11.21 Save 58%

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The ARP M10AF90-5 is a factory replacement 12-point bolt sourced directly from ARP's 230-4201 GM Duramax 6.6L cylinder head stud kit. Sold as a 5-pack, these individual bolts are ideal for service, replacement, or custom fastener applications where only the small 12-point cap screws from the kit are needed.

Each bolt features an M10 x 1.25 x 90mm specification with a compact 12-point head profile, manufactured to the same exacting ARP standards as the complete kit from which they originate. The 12-point head design allows for use in tighter clearance areas where a standard hex socket cannot reach.

Key Features:

  • Specification: M10 x 1.25 thread pitch x 90mm under-head length
  • Head Style: Small 12-point for tight-clearance installation
  • Material: ARP 8740 chromoly steel, black oxide finish
  • Tensile Strength: 220,000 PSI — far exceeding OEM hardware
  • Threads rolled after heat treatment for superior fatigue resistance and clamping retention
  • Quantity: Sold as a 5-pack
  • Sourced from: ARP Kit #230-4201 (GM 6.6L Duramax LB7/LLY/LBZ/LMM/LML Head Stud Kit)

ARP (Automotive Racing Products) is the industry standard in high-performance fasteners, trusted by professional engine builders and performance enthusiasts worldwide. These bolts meet ARP's strict quality benchmarks for dimensional accuracy, surface finish, and tensile strength.
